Home Products Proximity Sensor Pepperl Fuchs NMB10-18GM65-E0-V1 Pepperl Fuchs NMB10-18GM65-E0-V1 Proximity Sensor The Pepperl Fuchs NMB10-18GM65-E0-V1 Proximity Sensor offers a 10 mm operating distance, 3-wire, NPN, Normally open (NO), output, and flush (Requirements: see drawing below) installation. Manufactured by Pepperl Fuchs under the P&F Proximity Sensor category.
Brand Pepperl Fuchs Product Type Proximity Sensor Model Number NMB10-18GM65-E0-V1
Pepperl Fuchs NMB10-18GM65-E0-V1 Proximity Sensor β Technical Specifications Specification Value Switching function Normally open (NO) Output type 3-wire, NPN Rated operating distance 10 mm Installation flush (Requirements: see drawing below) Output polarity DC Assured operating distance 0 ... 8.1 mm Operating voltage 10 ... 30 V DC Switching frequency 0 ... 240 Hz Hysteresis 3 ... 15 typ. 10 % Reverse polarity protection reverse polarity protected Short-circuit protection pulsing Switching state indicator LED, yellow Ambient temperature -25 ... 70 Β°C (-13 ... 158 Β°F) Connection type Connector plug M12 x 1 , 4-pin Housing material Stainless steel 1.4305 / AISI 303 Sensing face Stainless steel 1.4305 / AISI 303 Degree of protection IP67
