Pepperl Fuchs NEB12-18GM50-E2-V1 Proximity Sensor
The Pepperl Fuchs NEB12-18GM50-E2-V1 Proximity Sensor offers a 12 mm operating distance, 3-wire, PNP, Normally open (NO), output, and quasi flush installation. Manufactured by Pepperl Fuchs under the P&F Proximity Sensor category.
| Brand | Pepperl Fuchs |
| Product Type | Proximity Sensor |
| Model Number | NEB12-18GM50-E2-V1 |
Pepperl Fuchs NEB12-18GM50-E2-V1 Proximity Sensor โ Technical Specifications
| Specification | Value |
|---|---|
| Switching function | Normally open (NO) |
| Output type | 3-wire, PNP |
| Rated operating distance | 12 mm |
| Installation | quasi flush |
| Output polarity | DC |
| Assured operating distance | 0 ... 9.72 mm |
| Operating voltage | 10 ... 30 V |
| Switching frequency | 0 ... 500 Hz |
| Hysteresis | 0.12 ... 1.8 mm |
| Reverse polarity protection | yes |
| Short-circuit protection | pulsing |
| Switching state indicator | LED, yellow |
| Ambient temperature | -25 ... 85 ยฐC (-13 ... 185 ยฐF) |
| Storage temperature | -40 ... 85 ยฐC (-40 ... 185 ยฐF) |
| Connection type | Connector plug M12 x 1 , 3-pin |
| Housing material | brass, nickel-plated |
| Sensing face | PBT |
| Degree of protection | IP67 |
| Mass | 50 g |
