Pepperl Fuchs NCN25-30GM50-Z4 Proximity Sensor
The Pepperl Fuchs NCN25-30GM50-Z4 Proximity Sensor offers a 25 mm operating distance, 2-wire, Normally open (NO), output, and non-flush installation. Manufactured by Pepperl Fuchs under the P&F Proximity Sensor category.
| Brand | Pepperl Fuchs |
| Product Type | Proximity Sensor |
| Model Number | NCN25-30GM50-Z4 |
Pepperl Fuchs NCN25-30GM50-Z4 Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Switching function | Normally open (NO) |
| Output type | 2-wire |
| Rated operating distance | 25 mm |
| Installation | non-flush |
| Output polarity | DC |
| Assured operating distance | 0 ... 20 mm |
| Operating voltage | 3.5 ... 30 V |
| Switching frequency | 500 Hz |
| Hysteresis | typ. 3 % |
| Reverse polarity protection | reverse polarity-conductive |
| Short-circuit protection | pulsing |
| Switching state indicator | LED, yellow |
| Ambient temperature | -25 ... 70 Β°C (-13 ... 158 Β°F) |
| Storage temperature | -25 ... 85 Β°C (-13 ... 185 Β°F) |
| Connection type | cable |
| Housing material | brass, nickel-plated |
| Sensing face | PBT |
| Degree of protection | IP67 |
