Home Products Proximity Sensor Pepperl Fuchs NBN50-U1K-E2 Pepperl Fuchs NBN50-U1K-E2 Proximity Sensor The Pepperl Fuchs NBN50-U1K-E2 Proximity Sensor offers a 50 mm operating distance, 3-wire, PNP, Normally open (NO), output, and non-flush installation. Manufactured by Pepperl Fuchs under the P&F Proximity Sensor category.
Brand Pepperl Fuchs Product Type Proximity Sensor Model Number NBN50-U1K-E2
Pepperl Fuchs NBN50-U1K-E2 Proximity Sensor – Technical Specifications Specification Value Switching function Normally open (NO) Output type 3-wire, PNP Rated operating distance 50 mm Installation non-flush Output polarity DC Assured operating distance 0 ... 40.5 mm Operating voltage 10 ... 30 V DC Switching frequency 0 ... 40 Hz Hysteresis typ. 5 % Reverse polarity protection reverse polarity protected Short-circuit protection pulsing Switching state indicator LED, yellow Ambient temperature -25 ... 70 °C (-13 ... 158 °F) Storage temperature -40 ... 85 °C (-40 ... 185 °F) Connection type screw terminals Housing material PA Sensing face PA Degree of protection IP68 / IP69 Mass 225 g
