Pepperl Fuchs NBN40-L2M-A0-V1 Proximity Sensor
The Pepperl Fuchs NBN40-L2M-A0-V1 Proximity Sensor offers a 40 mm operating distance, 4-wire, NPN, complementary, output, and non-flush installation. Manufactured by Pepperl Fuchs under the P&F Proximity Sensor category.
| Brand | Pepperl Fuchs |
| Product Type | Proximity Sensor |
| Model Number | NBN40-L2M-A0-V1 |
Pepperl Fuchs NBN40-L2M-A0-V1 Proximity Sensor โ Technical Specifications
| Specification | Value |
|---|---|
| Switching function | complementary |
| Output type | 4-wire, NPN |
| Rated operating distance | 40 mm |
| Installation | non-flush |
| Output polarity | DC |
| Assured operating distance | 0 ... 32.4 mm |
| Operating voltage | 10 ... 30 V DC |
| Switching frequency | 0 ... 180 Hz |
| Hysteresis | typ. 5 % |
| Reverse polarity protection | reverse polarity protected |
| Short-circuit protection | pulsing |
| Switching state indicator | LED, yellow |
| Ambient temperature | -25 ... 85 ยฐC (-13 ... 185 ยฐF) |
| Storage temperature | -40 ... 85 ยฐC (-40 ... 185 ยฐF) |
| Connection type | Connector plug M12 x 1 , 4-pin |
| Housing material | PA-GF35metal base Xylan coatedmetal mounting flange Xylan coated. |
| Sensing face | PA-GF35 |
| Degree of protection | IP69K |
