Pepperl Fuchs NBN30-FPS-A2 Proximity Sensor
The Pepperl Fuchs NBN30-FPS-A2 Proximity Sensor offers a 30 mm operating distance, 4-wire, PNP, complementary, output, and non-flush installation. Manufactured by Pepperl Fuchs under the P&F Proximity Sensor category.
| Brand | Pepperl Fuchs |
| Product Type | Proximity Sensor |
| Model Number | NBN30-FPS-A2 |
Pepperl Fuchs NBN30-FPS-A2 Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Switching function | complementary |
| Output type | 4-wire, PNP |
| Rated operating distance | 30 mm |
| Installation | non-flush |
| Output polarity | DC |
| Assured operating distance | 0 ... 24.3 mm |
| Operating voltage | 10 ... 30 V DC |
| Switching frequency | 0 ... 50 Hz |
| Hysteresis | 0.05 ... 7.26 mm |
| Reverse polarity protection | yes |
| Short-circuit protection | yes |
| Switching state indicator | LED, yellow |
| Ambient temperature | -25 ... 85 Β°C (-13 ... 185 Β°F) |
| Storage temperature | -40 ... 85 Β°C (-40 ... 185 Β°F) |
| Connection type | screw terminals |
| Housing material | PBT |
| Sensing face | PBT |
| Degree of protection | IP65 |
| Mass | 270 g |
