Home Products Proximity Sensor Pepperl Fuchs NBN2-F581-140S6-E8-V1 Pepperl Fuchs NBN2-F581-140S6-E8-V1 Proximity Sensor The Pepperl Fuchs NBN2-F581-140S6-E8-V1 Proximity Sensor offers a 2 mm operating distance, 4-wire, PNP, 2 x normally open (NO), output, and non-flush installation. Manufactured by Pepperl Fuchs under the P&F Proximity Sensor category.
Brand Pepperl Fuchs Product Type Proximity Sensor Model Number NBN2-F581-140S6-E8-V1
Pepperl Fuchs NBN2-F581-140S6-E8-V1 Proximity Sensor – Technical Specifications Specification Value Switching function 2 x normally open (NO) Output type 4-wire, PNP Rated operating distance 2 mm Installation non-flush Output polarity DC Assured operating distance 0 ... 1.62 mm Operating voltage 10 ... 30 V DC Switching frequency 0 ... 25 Hz Reverse polarity protection yes Short-circuit protection yes Ambient temperature -25 ... 70 °C (-13 ... 158 °F) Storage temperature -40 ... 85 °C (-40 ... 185 °F) Connection type Connector plug M12 x 1 , 4-pin Housing material amplifier; PBT, PA6 + GD-ZN AL4oscillators; PBT Degree of protection IP65
