Pepperl Fuchs NBN12-18GM30-E2 Proximity Sensor
The Pepperl Fuchs NBN12-18GM30-E2 Proximity Sensor offers a 12 mm operating distance, 3-wire, PNP, Normally open (NO), output, and non-flush installation. Manufactured by Pepperl Fuchs under the P&F Proximity Sensor category.
| Brand | Pepperl Fuchs |
| Product Type | Proximity Sensor |
| Model Number | NBN12-18GM30-E2 |
Pepperl Fuchs NBN12-18GM30-E2 Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Switching function | Normally open (NO) |
| Output type | 3-wire, PNP |
| Rated operating distance | 12 mm |
| Installation | non-flush |
| Output polarity | DC |
| Assured operating distance | 0 ... 9.72 mm |
| Operating voltage | 5 ... 36 V |
| Switching frequency | 0 ... 1300 Hz |
| Hysteresis | typ. 5 % |
| Reverse polarity protection | reverse polarity protected |
| Short-circuit protection | pulsing |
| Switching state indicator | LED, yellow |
| Ambient temperature | -40 ... 85 Β°C (-40 ... 185 Β°F) |
| Storage temperature | -40 ... 85 Β°C (-40 ... 185 Β°F) |
| Connection type | cable |
| Housing material | brass , white bronze coated |
| Sensing face | PBT , green |
| Degree of protection | IP65 / IP66 / IP67 / IP68 |
| Mass | 96 g |
| Tightening torque | 0 ... 30 Nm |
