Pepperl Fuchs NBB2-12GM60-E2-T Proximity Sensor
The Pepperl Fuchs NBB2-12GM60-E2-T Proximity Sensor offers a 2 mm operating distance, 3-wire, PNP, Normally open (NO), output, and flush installation. Manufactured by Pepperl Fuchs under the P&F Proximity Sensor category.
| Brand | Pepperl Fuchs |
| Product Type | Proximity Sensor |
| Model Number | NBB2-12GM60-E2-T |
Pepperl Fuchs NBB2-12GM60-E2-T Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Switching function | Normally open (NO) |
| Output type | 3-wire, PNP |
| Rated operating distance | 2 mm |
| Installation | flush |
| Assured operating distance | 0 ... 1.62 mm |
| Switching frequency | 0 ... 1200 Hz |
| Hysteresis | 0.02 ... 0.44 mm |
| Reverse polarity protection | yes |
| Short-circuit protection | yes |
| Switching state indicator | Multihole-LED, yellow |
| Ambient temperature | -25 ... 100 Β°C (-13 ... 212 Β°F) |
| Storage temperature | -40 ... 100 Β°C (-40 ... 212 Β°F) |
| Connection type | cable |
| Housing material | brass, nickel-plated |
| Sensing face | PBT |
| Degree of protection | IP67 |
| Mass | 87 g |
