Pepperl Fuchs NBB1,5-8GM40-Z0-300MM-V1: Inductive Sensors
Technical Specifications of Pepperl Fuchs Inductive Sensors NBB1,5-8GM40-Z0-300MM-V1:
| Rated operating distance | 1.5 mm |
| Installation | flush |
| Output type | 2-wire |
| Connection type | fixed cable with plug |
Pepperl Fuchs Inductive Sensors NBB1,5-8GM40-Z0-300MM-V1 Technical Specifications
| Specification | Value |
|---|---|
| Switching function | Normally open (NO) |
| Output type | 2-wire |
| Rated operating distance | 1.5 mm |
| Installation | flush |
| Assured operating distance | 0 ... 1.21 mm |
| Actual operating distance | 1.35 ... 1.65 mm typ. |
| Reduction factor rAl | 0.22 |
| Reduction factor rCu | 0.16 |
| Reduction factor r304 | 0.64 |
| Nominal voltage | - |
| Switching frequency | 0 ... 1200 Hz |
| Hysteresis | 1 ... 10 % typ. 5 % |
| Reverse polarity protection | reverse polarity tolerant |
| Short-circuit protection | pulsing |
| Current Consumption | - |
| Switching state indicator | LED, yellow |
| Ambient temperature | -25 ... 70 Β°C (-13 ... 158 Β°F) |
| Storage temperature | - |
| Connection type | fixed cable with plug |
| Housing material | Stainless steel 1.4305 / AISI 303 |
| Sensing face | LCP |
| Degree of protection | IP67 |
| Mass | 32 g |
| Tightening torque | - |
