In most procurement cycles, NBB15-30GM50-A2 is considered with Omron Proximity Sensors, P&F Sensors and P&F Photoelectric Sensor, giving decision-makers confidence that theyโve chosen the most dependable component.
Pepperl Fuchs NBB15-30GM50-A2 Proximity Sensor
The Pepperl Fuchs NBB15-30GM50-A2 Proximity Sensor offers a 15 mm operating distance, 4-wire, PNP, complementary, output, and flush installation. Manufactured by Pepperl Fuchs under the P&F Proximity Sensor category.
| Brand | Pepperl Fuchs |
| Product Type | Proximity Sensor |
| Model Number | NBB15-30GM50-A2 |
Pepperl Fuchs NBB15-30GM50-A2 Proximity Sensor โ Technical Specifications
| Specification | Value |
|---|---|
| Switching function | complementary |
| Output type | 4-wire, PNP |
| Rated operating distance | 15 mm |
| Installation | flush |
| Output polarity | DC |
| Assured operating distance | 0 ... 12.15 mm |
| Operating voltage | 5 ... 36 V |
| Switching frequency | 0 ... 550 Hz |
| Hysteresis | typ. 5 % |
| Reverse polarity protection | reverse polarity protected |
| Short-circuit protection | pulsing |
| Switching state indicator | LED, yellow |
| Ambient temperature | -40 ... 85 ยฐC (-40 ... 185 ยฐF) |
| Storage temperature | -40 ... 85 ยฐC (-40 ... 185 ยฐF) |
| Connection type | cable |
| Housing material | brass , white bronze coated |
| Sensing face | PBT , green |
| Degree of protection | IP65 / IP66 / IP67 / IP68 |
| Mass | 198 g |
| Tightening torque | 0 ... 30 Nm |
