Home Products Photoelectric Sensor Pepperl Fuchs MLV41-6-IO/98/103 Pepperl Fuchs MLV41-6-IO/98/103 Photoelectric Sensor The Pepperl Fuchs MLV41-6-IO/98/103 Photoelectric Sensor offers a 0 ... 9.5 m detection range, LED light source, and M8 x 1 connector, 3-pin connection. Manufactured by Pepperl Fuchs under the P&F Photoelectric Sensor category, this model belongs to the reflective sensor.
Brand Pepperl Fuchs Product Type Photoelectric Sensor Model Number MLV41-6-IO/98/103
Pepperl Fuchs MLV41-6-IO/98/103 Photoelectric Sensor β Technical Specifications Specification Value Effective detection range 0 ... 9.5 m Reflector distance Foil reflector 0.05 ... 3 mRetro-reflector 0.01 ... 9.5 m Threshold detection range 12 m Reference target OFR-22800/76 , H85-2 reflector Light source LED Light type modulated visible red light , 625 nm Polarization filter no Diameter of the light spot approx. 300 mm at detection range 8.5 m Opening angle 1.5 Β° Optical face frontal Control elements none Operating voltage 10 ... 30 V DC Ripple max. 10 % No-load supply current max. 30 mA Switching type - Signal output 1 PNP output, short-circuit protected, reverse polarity protected, open collector Switching voltage max. 30 V DC Switching current max. 100 mA Voltage drop β€ 2.5 V DC Switching frequency 1000 Hz Response time 0.5 ms Ambient temperature -20 ... 60 Β°C (-4 ... 140 Β°F)60 ... 70 Β°C (140 ... 158 Β°F) ; max. 20,000 hours = 2.5 years (continuous operation) Storage temperature -40 ... 75 Β°C (-40 ... 167 Β°F) Degree of protection IP67 Connection M8 x 1 connector, 3-pin Mass 50 g Cable length -
