Pepperl Fuchs ML300-55-6m-RT/25/95/120 Photoelectric Sensor
The Pepperl Fuchs ML300-55-6m-RT/25/95/120 Photoelectric Sensor offers a 0 ... 6 m detection range, LED light source, and M8 x 1 connector, 4-pin connection. Manufactured by Pepperl Fuchs under the P&F Photoelectric Sensor category, this model belongs to the reflective sensor.
| Brand | Pepperl Fuchs |
| Product Type | Photoelectric Sensor |
| Model Number | ML300-55-6m-RT/25/95/120 |
Pepperl Fuchs ML300-55-6m-RT/25/95/120 Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Effective detection range | 0 ... 6 m |
| Reflector distance | 0.03 ... 6 m |
| Threshold detection range | 7 m |
| Reference target | H85-2 reflector |
| Light source | LED |
| Light type | modulated visible red light , 660 nm |
| Polarization filter | yes |
| Diameter of the light spot | approx. 300 mm at 4 m |
| Opening angle | approx. 3 Β° |
| Optical face | - |
| Control elements | sensitivity adjustment |
| Operating voltage | 10 ... 30 V DC |
| Ripple | max. 20 % |
| No-load supply current | max. 20 mA |
| Switching type | light on / dark on |
| Signal output | 2 PNP outputs, complementary, short-circuit protected, reverse polarity protected, open collector |
| Switching voltage | max. 30 V DC |
| Switching current | max. 0.1 A |
| Voltage drop | β€ 2 V DC |
| Switching frequency | 1000 Hz |
| Response time | 0.5 ms |
| Ambient temperature | -25 ... 55 Β°C (-13 ... 131 Β°F) |
| Storage temperature | - |
| Degree of protection | IP67 |
| Connection | M8 x 1 connector, 4-pin |
| Mass | 18 g |
| Cable length | - |
