Pepperl Fuchs ML17-54/59/103/115a/154 Photoelectric Sensor
The Pepperl Fuchs ML17-54/59/103/115a/154 Photoelectric Sensor offers a 0 ... 3.5 m detection range, LED light source, and 150 mm PVC cable with 4-pin, M8 connector connection. Manufactured by Pepperl Fuchs under the P&F Photoelectric Sensor category, this model belongs to the reflective sensor.
| Brand | Pepperl Fuchs |
| Product Type | Photoelectric Sensor |
| Model Number | ML17-54/59/103/115a/154 |
Pepperl Fuchs ML17-54/59/103/115a/154 Photoelectric Sensor โ Technical Specifications
| Specification | Value |
|---|---|
| Effective detection range | 0 ... 3.5 m |
| Reflector distance | 50 ... 3500 mm |
| Threshold detection range | 5 m |
| Reference target | FE-RR1 reflector |
| Light source | LED |
| Light type | modulated visible red light , 626 nm |
| Polarization filter | yes |
| Diameter of the light spot | - |
| Opening angle | - |
| Optical face | - |
| Control elements | - |
| Operating voltage | 10 ... 30 V DC , class 2 |
| Ripple | max. 10 % |
| No-load supply current | < 25 mA |
| Switching type | dark-on |
| Signal output | 1 PNP, short-circuit protected, reverse polarity protected |
| Switching voltage | max. 30 V DC |
| Switching current | max. 100 mA |
| Voltage drop | โค 2.5 V DC |
| Switching frequency | 500 Hz |
| Response time | โค 1 ms |
| Ambient temperature | -20 ... 55 ยฐC (-4 ... 131 ยฐF) |
| Storage temperature | -20 ... 70 ยฐC (-4 ... 158 ยฐF) |
| Degree of protection | IP67 |
| Connection | 150 mm PVC cable with 4-pin, M8 connector |
| Mass | approx. 40 g |
| Cable length | - |
