Pepperl Fuchs MD17/33/115-10M Photoelectric Sensor

Name: Pepperl Fuchs MD17/33/115-10M Photoelectric Sensor
Brand: Pepperl Fuchs
SKU: MD17/33/115-10M
Rating: 4.3 (7 reviews)

The Pepperl Fuchs MD17/33/115-10M Photoelectric Sensor offers a 0 ... 15 m detection range, and 10 m cable, fixed installation connection. Manufactured by Pepperl Fuchs under the P&F Photoelectric Sensor category, this model belongs to the through beam sensor.

Datasheet

Brand	Pepperl Fuchs
Product Type	Photoelectric Sensor
Model Number	MD17/33/115-10M

Pepperl Fuchs MD17/33/115-10M Photoelectric Sensor – Technical Specifications

Specification	Value
Emitter	MD17/33/115-10M
Receiver	MV17/33/115/136-10M
Effective detection range	0 ... 15 m
Threshold detection range	20 m
Light source	IRED
Light type	Infrared LED
Optical face	Acrylic
Operation indicator	LED green
Operating voltage	10 ... 30 V DC , class 2
Ripple	max. 10 %
No-load supply current	< 25 mA
Ambient temperature	-20 ... 55 °C (-4 ... 131 °F)
Storage temperature	-20 ... 70 °C (-4 ... 158 °F)
Degree of protection	IP67
Connection	10 m cable, fixed installation
Housing	ABS
Mass	approx. 190 g
Height	34.5 mm
Width	15 mm
