Pepperl Fuchs KFU8-SR-Ex2-W Intrinsic Safety Barrier
The Pepperl Fuchs KFU8-SR-Ex2-W Intrinsic Safety Barrier offers a Digital Input signal type, on 35 mm DIN mounting rail, and screw terminals connection. Manufactured by Pepperl Fuchs under the P&F Intrinsic Safety Barrier category.
| Brand | Pepperl Fuchs |
| Product Type | Intrinsic Safety Barrier |
| Model Number | KFU8-SR-Ex2-W |
Pepperl Fuchs KFU8-SR-Ex2-W Intrinsic Safety Barrier – Technical Specifications
| Specification | Value |
|---|---|
| Signal type | Digital Input |
| Safety Integrity Level (SIL) | SIL 2 |
| Systematic capability (SC) | SC 3 |
| Supply Connection | terminals 14, 15 |
| Rated voltage | 19 ... 30 V DC / 90 ... 253 V AC 50 ... 60 Hz |
| Rated current | - |
| Power dissipation | ≤ 1.3 W / ≤ 1.3 W ; 3.6 VA |
| Power consumption | ≤ 1.3 W / ≤ 1.3 W ; 3.6 VA |
| Connection side (Input) | field side |
| Ripple | - |
| Connection (Input) | terminals 1+, 2+, 3-; 4+, 5+, 6- |
| Open circuit voltage/short-circuit current (Input) | approx. 8 V DC / approx. 8 mA |
| Switching point/switching hysteresis (Input) | 1.2 ... 2.1 mA / approx. 0.2 mA |
| Connection side (Output) | control side |
| Connection (Output) | output I: terminals 7, 8, 9 ; output II: terminals 10, 11, 12 |
| Response time | - |
| Signal level | - |
| Output I | signal ; relay |
| Output II | signal ; relay |
| Minimum switch current | 2 mA / 24 V DC |
| Switching frequency | ≤ 10 Hz |
| Display elements | LEDs |
| Control elements | DIP switch |
| Dimensions | 20 x 119 x 115 mm (0.8 x 4.7 x 4.5 inch) |
| Connection | screw terminals |
| Mounting | on 35 mm DIN mounting rail |
| Ambient temperature | -40 ... 60 °C (-40 ... 140 °F) |
| Degree of protection | IP20 |
Call us for P&F ≤ 1.3 W Power Consumption Switching Amplifier, KFU8-SR-Ex2-W at the best rates. Technical Attributes of KFU8-SR-Ex2-W, are Digital Input signal type, terminals 14, 15 supply connection, Digital Input rated voltage, - rated curent, field side input connection, -, response time, control side, output connection, signal ; relay output, ≤ 10 Hz switching frequency, with dimensions of 20 x 119 x 115 mm (0.8 x 4.7 x 4.5 inch) screw terminals connection, on 35 mm DIN mounting rail mounting, -40 ... 60 °C (-40 ... 140 °F) ambient temperature IP20 degree of protection. Unlock Exclusive Pricing with a Quote for your requirement of P&F ≤ 1.3 W Power Consumption Switching Amplifier. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
