Pepperl Fuchs KFD2-VR2-Ex1-50M Repeater
The Pepperl Fuchs KFD2-VR2-Ex1-50M Repeater offers a Analog input signal type, -50 ... 50 mV, and screw terminals connection. Manufactured by Pepperl Fuchs under the P&F Repeater category.
| Brand | Pepperl Fuchs |
| Product Type | Intrinsic Safety Barrier |
| Model Number | KFD2-VR2-Ex1-50M |
Pepperl Fuchs KFD2-VR2-Ex1-50M Repeater β Technical Specifications
| Specification | Value |
|---|---|
| Signal type | Analog input |
| Safety Integrity Level (SIL) | - |
| Supply Connection | Power Rail or terminals 14+, 15- |
| Rated voltage | 19 ... 30 V DC |
| Ripple | within the supply tolerance |
| Power dissipation | 0.3 W max. |
| Power consumption | 0.3 W max. |
| Connection side (Input) | field side |
| Connection (Input) | terminals 4+, 5- |
| Input resistance | min. 20 MΞ© |
| Output current | - |
| Transmission range | -50 ... 50 mV |
| Connection side (Output) | control side |
| Connection (Output) | terminals 7-, 8+ |
| Output Voltage | -50 ... 50 mV |
| Output/power supply | functional insulation, rated insulation voltage 50 V AC |
| Display elements | LED |
| Conformity Electromagnetic compatibility | NE 21:2006 |
| Degree of protection | IEC 60529:2001 |
| Ambient temperature | -40 ... 60 Β°C (-40 ... 140 Β°F) extended ambient temperature range up to 70 Β°C (158 Β°F), refer to manual for necessary mounting conditions |
| Degree of protection | IP20 |
| Connection | screw terminals |
| Mass | approx. 125 g |
| Dimensions | 20 x 119 x 115 mm (0.8 x 4.7 x 4.5 inch) (W x H x D) , housing type B2 |
| EU-type examination certificate | BASEEFA 06 ATEX 0040 |
| Certificate | BASEEFA 09 ATEX 0219X |
Send Your Inquiry for Pepperl Fuchs Voltage Repeaters KFD2-VR2-Ex1-50M with cost-effective solutions. Essential Technical Specs of KFD2-VR2-Ex1-50M are Analog input, - rated device operates on a 19 ... 30 V DC
power supply via Power Rail or terminals 14+, 15-. It features a low power consumption of 0.3 W max.. The field side includes terminals for common, supply, and signal, with 10 kΞ© impedance. It supports -50 ... 50 mV on the control side and offers functional insulation with a rated voltage of 110 V AC. Compliant with NE 21:2006 standards, it operates in temperatures from -40 ... 60 Β°C (-40 ... 140 Β°F) extended ambient temperature range up to 70 Β°C (158 Β°F), refer to manual for necessary mounting conditions, with an IP20 rating. The unit's compact housing measures 20 x 119 x 115 mm (0.8 x 4.7 x 4.5 inch) (W x H x D) , housing type B2 and weighs approximately approx. 125 g. It includes screw terminals for easy installation and an LED indicator. Capture the Best Deal with a Quote for your requirement of Pepperl Fuchs Voltage Repeaters. Our pricing and support are designed to exceed the standards of other Traders & Suppliers.
