Pepperl Fuchs KFD2-UFC-Ex1-D Frequency Converter
The Pepperl Fuchs KFD2-UFC-Ex1-D Frequency Converter offers a Digital Input signal type, on 35 mm DIN mounting rail , and screw terminals connection. Manufactured by Pepperl Fuchs under the P&F Frequency Converter category.
| Brand | Pepperl Fuchs |
| Product Type | Frequency Converter |
| Model Number | KFD2-UFC-Ex1-D |
Pepperl Fuchs KFD2-UFC-Ex1-D Frequency Converter β Technical Specifications
| Specification | Value |
|---|---|
| Signal type | Digital Input |
| Safety Integrity Level (SIL) | SIL 2 |
| Supply Connection | terminals 23+, 24- or power feed module/Power Rail |
| Rated voltage | 20 ... 30 V DC |
| Rated current | approx. 100 mA |
| Power dissipation/power consumption | β€ 2 W / 2.2 W |
| Connection side (Input) | field side |
| Connection (Input) | Input I: intrinsically safe: terminals 1+, 3- Input II: non-intrinsically safe: terminals 13+, 14- |
| Pulse duration (Input) | - |
| Input frequency | - |
| Connection side (Output) | control side |
| Connection (Output) | output I: terminals 10, 11, 12 output II: terminals 16, 17, 18 outout III: terminasl 19+, 20- output IV: terminals 8+, 7- |
| Output I, II | signal, relay |
| Measurement range | 0.001 ... 5000 Hz |
| Resolution | 0.1 % of the measurement value , β₯ 0.001 Hz |
| Measuring time | < 100 ms |
| Display elements | LEDs , display |
| Control elements | Control panel |
| Labeling | space for labeling at the front |
| Dimensions | 40 x 119 x 115 mm (1.6 x 4.7 x 4.5 inch) |
| Connection | screw terminals |
| Mounting | on 35 mm DIN mounting rail |
| Ambient temperature | -20 ... 60 Β°C (-4 ... 140 Β°F) |
| Degree of protection | IP20 |
| Mass | 300 g |
Mail Us for KFD2-UFC-Ex1-D Pepperl Fuchs Digital Input Frequency Converters at the lowest pricing. Technical Specs Summary of KFD2-UFC-Ex1-D, are digital input with a SIL 2 rating and operates with a power feed module or power rail input voltage of 20-30 V DC, consuming approximately 100 mA and a maximum of 2.2 W. The field side connections are made via intrinsically safe terminals 1+, 3- (Input I) and non-intrinsically safe terminals 13+, 14- (Input II). The control side connections include output I (terminals 10, 11, 12), output II (terminals 16, 17, 18), output III (terminals 19+, 20-), and output IV (terminals 8+, 7-).
The device supports a frequency range of 0.001 to 5000 Hz with an accuracy of 0.1% of the measurement value, a response time of less than 100 ms, and features LEDs and a display for monitoring. It provides space for labeling at the front, with dimensions of 40 x 119 x 115 mm, and mounts on a 35 mm DIN rail using screw terminals. The operating temperature range is -20 to 60 Β°C, with an IP20 rating, and it weighs approximately 300 g. Navigate Your Needs with a Quote for your requirement of Pepperl Fuchs Digital Input Frequency Converters. We excel in offering more cost-effective and supportive solutions than other Competitors.
