Pepperl Fuchs KFD2-STC4-Ex1-2O Transmitter Power Supplies
The Pepperl Fuchs KFD2-STC4-Ex1-2O Transmitter Power Supplies offers a Analog input signal type, on 35 mm DIN mounting rail, and screw terminals connection. Manufactured by Pepperl Fuchs under the P&F Transmitter Power Supplies category.
| Brand | Pepperl Fuchs |
| Product Type | Transmitter Power Supplies |
| Model Number | KFD2-STC4-Ex1-2O |
Pepperl Fuchs KFD2-STC4-Ex1-2O Transmitter Power Supplies β Technical Specifications
| Specification | Value |
|---|---|
| Signal type | Analog input |
| Safety Integrity Level (SIL) | SIL 3 |
| Systematic capability (SC) | - |
| Supply Connection | Power Rail or terminals 14+, 15- |
| Rated voltage | 20 ... 35 V DC |
| Ripple | within the supply tolerance |
| Rated current | - |
| Power dissipation | 1.8 W |
| Power consumption | 2.4 W |
| Connection side (Input) | field side |
| Connection (Input) | terminals 1+, 2-, 3 or 5-, 6+ |
| Input signal | 0/4 ... 20 mA |
| Open circuit voltage/short-circuit current (Input) | terminals 1+, 3-: 22.7 V / 38 mA |
| Input resistance | terminals 2-, 3: max. 76 Ξ©, terminals 1+, 3: max. 500 Ξ© (250 Ξ© load) |
| Available voltage | terminals 1+, 3: β₯ 16 V at 20 mA |
| Connection side (Output) | control side |
| Connection (Output) | terminals 7-, 8+,9; 10-, 11+,12 |
| Load | 0 ... 550 Ξ© at 20 mA |
| Output signal | 0/4 ... 20 mA (overload > 25 mA) |
| Frequency range | field side into the control side: bandwidth with 0.5 Vpp signal 0 ... 7.5 kHz (-3 dB), control side into the field side: bandwidth with 0.5 Vpp signal 0.3 ... 7.5 kHz (-3 dB) |
| Settling time | 200 Β΅s |
| Display elements | LED |
| Labeling | space for labeling at the front |
| Dimensions | 20 x 124 x 115 mm (0.8 x 4.9 x 4.5 inch) |
| Connection | screw terminals |
| Mounting | on 35 mm DIN mounting rail |
| Ambient temperature | -20 ... 60 Β°C (-4 ... 140 Β°F) |
| Degree of protection | IP20 |
| Mass | approx. 200 g |
Mail Us for your needs in P&F SIL 3 Transmitter Power Supplies KFD2-STC4-Ex1-2O with budget-friendly prices. The Main Technical Parameters of 20 x 124 x 115 mm (0.8 x 4.9 x 4.5 inch) include Analog input with 0/4 ... 20 mA range, SIL 3 and - ratings. Operating on 20 ... 35 V DC it consumes 1.8 W. The field side connects via input connection, terminals 1+, 2-, 3 or 5-, 6+, supporting up to 0 ... 550 Ξ© at 20 mA. The control side includes terminals 7-, 8+,9; 10-, 11+,12. It features a 200 Β΅s settling time, and LED indicators. The unit measures 20 x 124 x 115 mm (0.8 x 4.9 x 4.5 inch), mounts on a 66mm DIN rail, and operates between -20 ... 60 Β°C (-4 ... 140 Β°F). With a an IP60 rating and approximately approx. 200 g weight, it ensures reliable performance. Customize Your Experience with a Quote for your requirement of P&F SIL 3 Transmitter Power Supplies. Experience the difference with our competitive pricing and superior support over other Suppliers.
