Pepperl Fuchs KFD2-SR2-Ex2-2S Intrinsic Safety Barrier
The Pepperl Fuchs KFD2-SR2-Ex2-2S Intrinsic Safety Barrier offers a Digital Input signal type, on 35 mm DIN mounting rail, and screw terminals connection. Manufactured by Pepperl Fuchs under the P&F Intrinsic Safety Barrier category.
| Brand | Pepperl Fuchs |
| Product Type | Intrinsic Safety Barrier |
| Model Number | KFD2-SR2-Ex2-2S |
Pepperl Fuchs KFD2-SR2-Ex2-2S Intrinsic Safety Barrier β Technical Specifications
| Specification | Value |
|---|---|
| Signal type | Digital Input |
| Safety Integrity Level (SIL) | SIL 2 |
| Systematic capability (SC) | - |
| Supply Connection | Power Rail or terminals 14+, 15- |
| Rated voltage | 20 ... 30 V DC |
| Rated current | β€ 50 mA |
| Power dissipation | 1 W |
| Power consumption | < 1.3 W |
| Connection side (Input) | field side |
| Ripple | β€ 10 % |
| Connection (Input) | terminals 1+, 2+, 3-; 4+, 5+, 6- |
| Open circuit voltage/short-circuit current (Input) | approx. 8 V DC / approx. 8 mA |
| Switching point/switching hysteresis (Input) | 1.2 ... 2.1 mA / approx. 0.2 mA |
| Connection side (Output) | control side |
| Connection (Output) | output I: terminals 7, 8 ; output II: terminals 8, 9 ; output III: terminals 10, 11 ; output IV: terminals 11, 12 |
| Response time | - |
| Signal level | - |
| Output I | channel 1, 2; relay |
| Output II | channel 1, 2; relay |
| Minimum switch current | 1 mA / 24 V DC |
| Switching frequency | β€ 10 Hz |
| Display elements | LEDs |
| Control elements | DIP switch |
| Dimensions | 20 x 119 x 115 mm (0.8 x 4.7 x 4.5 inch) |
| Connection | screw terminals |
| Mounting | on 35 mm DIN mounting rail |
| Ambient temperature | -20 ... 60 Β°C (-4 ... 140 Β°F) |
| Degree of protection | IP20 |
IndMALL Offers Pepperl Fuchs 24 V DC Switch Amplifiers KFD2-SR2-Ex2-2S at the lowest pricing. Technical Specs Summary of KFD2-SR2-Ex2-2S, includes Digital Input signal type, Power Rail or terminals 14+, 15- supply connection, Digital Input rated voltage, β€ 50 mA rated curent, field side input connection, -, response time, control side, output connection, channel 1, 2; relay output, β€ 10 Hz switching frequency, with dimensions of 20 x 119 x 115 mm (0.8 x 4.7 x 4.5 inch) screw terminals connection, on 35 mm DIN mounting rail mounting, -20 ... 60 Β°C (-4 ... 140 Β°F) ambient temperature IP20 degree of protection. Now's the Time to Secure a Quote for your requirement of Pepperl Fuchs 24 V DC Switch Amplifiers. We're committed to offering more favorable pricing and more responsive support than other Traders.
