Pepperl Fuchs KFD2-SLD-Ex2-1045-Y1 Solenoid Driver
The Pepperl Fuchs KFD2-SLD-Ex2-1045-Y1 Solenoid Driver offers a Digital Output signal type, on 35 mm DIN mounting rail , and screw terminals connection. Manufactured by Pepperl Fuchs under the P&F Solenoid Driver category.
| Brand | Pepperl Fuchs |
| Product Type | Solenoid Driver |
| Model Number | KFD2-SLD-Ex2-1045-Y1 |
Pepperl Fuchs KFD2-SLD-Ex2-1045-Y1 Solenoid Driver β Technical Specifications
| Specification | Value |
|---|---|
| Signal type | Digital Output |
| Safety Integrity Level (SIL) | - |
| Systematic capability (SC) | - |
| Supply Connection | Power Rail or terminals 14+, 15- |
| Rated voltage | 18... 30 V DC |
| Rated current | - |
| Power dissipation | - |
| Power consumption | max. 3.5 W at 45 mA output current |
| Connection side (Input) | control side |
| Connection (Input) | terminals 7, 8, 9 |
| Signal Level | loop powered 1-signal: 18 ... 30 V DC 0-signal: 0 ... 5 V DC bus powered 1-signal: 15 ... 30 V DC (current limited to 5 mA) 0-signal: 0 ... 5 V DC |
| Inrush current(Input) | β€ 200 mA after 100 Β΅s |
| Connection side (Output) | field side |
| Connection (Output) | channel 1: terminals 1+, 2-, 3- channel 2: terminals 4+, 5-, 6- |
| Internal resistor | 276 Ξ© |
| Current | 45 mA |
| Voltage | β₯ 10 V |
| Output current | 45 mA |
| Switching frequency | - |
| Display elements | LEDs |
| Control elements | DIP switch |
| Labeling | space for labeling at the front |
| Dimensions | 20 x 119 x 115 mm (0.8 x 4.7 x 4.5 inch) |
| Connection | screw terminals |
| Mounting | on 35 mm DIN mounting rail |
| Ambient temperature | -40 ... 60 Β°C (-40 ... 140 Β°F) |
| Degree of protection | IP20 |
| Mass | approx. 150 g |
Mail Us for P&F 2-Channel, 45mA at 10V, Solenoid Driver KFD2-SLD-Ex2-1045-Y1 at unbeatable prices. Detailed Specifications of KFD2-SLD-Ex2-1045-Y1, feature digital output and operates with a power rail or bus-powered input voltage of 18-30 V DC, with a maximum power consumption of 3.5 W at 45 mA output current. The control side connects via terminals 7, 8, 9, supporting both loop-powered (1-signal: 18-30 V DC, 0-signal: 0-5 V DC) and bus-powered (1-signal: 15-30 V DC, 0-signal: 0-5 V DC) configurations. The device supports currents up to 200 mA after 100 Β΅s.
The field side connects via channel 1 (terminals 1+, 2-, 3-) and channel 2 (terminals 4+, 5-, 6-), with a resistance of 276 Ξ© and a typical current of 45 mA at β₯ 10 V. The unit includes LED indicators, a DIP switch, and space for labeling at the front. Dimensions are 20 x 119 x 115 mm, and it mounts on a 35 mm DIN rail using screw terminals. It operates in temperatures ranging from -40 to 60 Β°C, with an IP20 rating, and weighs approximately 150 g. Elevate Your Project with a Quote for your requirement of P&F 2-Channel, 45mA at 10V, Solenoid Driver. Count on us for more economical pricing and more reliable support than other Traders & Suppliers.
