Pepperl Fuchs KFD2-SLD-Ex1-13100 Solenoid Driver
The Pepperl Fuchs KFD2-SLD-Ex1-13100 Solenoid Driver offers a Digital Output signal type, on 35 mm DIN mounting rail , and screw terminals connection. Manufactured by Pepperl Fuchs under the P&F Solenoid Driver category.
| Brand | Pepperl Fuchs |
| Product Type | Solenoid Driver |
| Model Number | KFD2-SLD-Ex1-13100 |
Pepperl Fuchs KFD2-SLD-Ex1-13100 Solenoid Driver β Technical Specifications
| Specification | Value |
|---|---|
| Signal type | Digital Output |
| Safety Integrity Level (SIL) | SIL 3 |
| Systematic capability (SC) | SC 3 |
| Supply Connection | Power Rail or terminals 14+, 15- |
| Rated voltage | 19 ... 30 V DC loop powered |
| Rated current | 115 mA at 24 V , 130 Ξ© load |
| Power dissipation | 1.5 W at 24 V , 130 Ξ© load |
| Power consumption | - |
| Connection side (Input) | control side |
| Connection (Input) | channel 1: terminals 7+, 8- , optional Rext between terminals 7 and 9 channel 2: terminals 10+, 11- , optional Rext between terminals 10 and 12 |
| Signal Level | 1-signal: 15 ... 30 V DC 0-signal: 0 ... 5 V DC |
| Inrush current(Input) | - |
| Connection side (Output) | field side |
| Connection (Output) | channel 1: terminals 1+, 2-, 3 channel 2: terminals 4+, 5-, 6- |
| Internal resistor | approx. 64 Ξ© |
| Current | typ. 100 mA |
| Voltage | β₯ 13 V |
| Output current | 105 mA |
| Switching frequency | max. 2 Hz |
| Display elements | LEDs |
| Control elements | DIP switch |
| Labeling | space for labeling at the front |
| Dimensions | 20 x 119 x 115 mm (0.8 x 4.7 x 4.5 inch) |
| Connection | screw terminals |
| Mounting | on 35 mm DIN mounting rail |
| Ambient temperature | -20 ... 60 Β°C (-4 ... 140 Β°F) |
| Degree of protection | IP20 |
| Mass | approx. 200 g |
Reach Us by Email for IndMALL Automation offers the Pepperl Fuchs SC3 Solenoid Driver KFD2-SLD-Ex1-13100. This solenoid driver features digital output with SIL 3 and SC 3 ratings, operating with a power rail or loop-powered input voltage of 19-30 V DC, consuming 115 mA at 24 V with a 130 Ξ© load and 1.5 W at 24 V with a 130 Ξ© load. The control side connects via channel 1 (terminals 7+, 8- with optional Rext between terminals 7 and 9) and channel 2 (terminals 10+, 11- with optional Rext between terminals 10 and 12), providing a 1-signal voltage of 15-30 V DC and a 0-signal voltage of 0-5 V DC. The field side connects via channel 1 (terminals 1+, 2-, 3) and channel 2 (terminals 4+, 5-, 6-), with an approximate resistance of 64 Ξ© and a typical current of 100 mA at β₯ 13 V. The unit includes LED indicators, a DIP switch, and space for labeling at the front. Dimensions are 20 x 119 x 115 mm, and it mounts on a 35 mm DIN rail. Navigate Your Needs with a Quote for your requirement of Pepperl Fuchs SC3 Solenoid Drivers. Our pricing and support are unrivaled, especially when compared to other Competitors.
