Home Products Photoelectric Sensor Pepperl Fuchs GLV18-6-S/25/102/115 Pepperl Fuchs GLV18-6-S/25/102/115 Photoelectric Sensor The Pepperl Fuchs GLV18-6-S/25/102/115 Photoelectric Sensor offers a 0 ... 5.5 m detection range, LED light source, and 2 m fixed cable connection. Manufactured by Pepperl Fuchs under the P&F Photoelectric Sensor category, this model belongs to the reflective sensor.
Brand Pepperl Fuchs Product Type Photoelectric Sensor Model Number GLV18-6-S/25/102/115
Pepperl Fuchs GLV18-6-S/25/102/115 Photoelectric Sensor – Technical Specifications Specification Value Effective detection range 0 ... 5.5 m Reflector distance 0.05 ... 5.5 m Threshold detection range 6.5 m Reference target reflector C110-2 Light source LED Light type modulated visible red light , 640 nm Polarization filter no Diameter of the light spot approx. 250 mm at 6.5 m Opening angle approx. 2 ° Optical face lateral Control elements - Operating voltage 10 ... 30 V DC Ripple - No-load supply current < 20 mA Switching type light-on Signal output 1 NPN, short-circuit protected open collector Switching voltage max. 30 V DC Switching current max. 100 mA Voltage drop ≤ 1.5 V DC Switching frequency 500 Hz Response time ≤ 1 ms Ambient temperature -25 ... 60 °C (-13 ... 140 °F) Storage temperature -40 ... 70 °C (-40 ... 158 °F) Degree of protection IP67 Connection 2 m fixed cable Mass approx. 75 g Cable length -
