Pepperl Fuchs GLV18-6-4594-10M Photoelectric Sensor
The Pepperl Fuchs GLV18-6-4594-10M Photoelectric Sensor offers a 0 ... 4 m detection range, IRED light source, and fixed cable 10 m connection. Manufactured by Pepperl Fuchs under the P&F Photoelectric Sensor category, this model belongs to the reflective sensor.
| Brand | Pepperl Fuchs |
| Product Type | Photoelectric Sensor |
| Model Number | GLV18-6-4594-10M |
Pepperl Fuchs GLV18-6-4594-10M Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Effective detection range | 0 ... 4 m |
| Reflector distance | 0.05 ... 4 m |
| Threshold detection range | 5.5 m |
| Reference target | reflector C110-2 |
| Light source | IRED |
| Light type | IRED , Modulated light , 880 nm |
| Polarization filter | no |
| Diameter of the light spot | approx. 200 mm at 5.5 m |
| Opening angle | approx. 2 Β° |
| Optical face | frontal |
| Control elements | - |
| Operating voltage | 10 ... 30 V DC |
| Ripple | - |
| No-load supply current | < 20 mA |
| Switching type | light-on |
| Signal output | 1 PNP, short-circuit protected, open collector |
| Switching voltage | max. 30 V DC |
| Switching current | max. 100 mA |
| Voltage drop | β€ 1.5 V DC |
| Switching frequency | 500 Hz |
| Response time | β€ 1 ms |
| Ambient temperature | -25 ... 60 Β°C (-13 ... 140 Β°F) |
| Storage temperature | -40 ... 70 Β°C (-40 ... 158 Β°F) |
| Degree of protection | IP67 |
| Connection | fixed cable 10 m |
| Mass | approx. 335 g |
| Cable length | - |
