Pepperl Fuchs CJ10-30GM-WS Proximity Sensor
The Pepperl Fuchs CJ10-30GM-WS Proximity Sensor offers a 10 mm operating distance, 2-wire, Normally open (NO), output, cable, output, and non-flush installation. Manufactured by Pepperl Fuchs under the P&F Proximity Sensor category, this model belongs to the Capacitive sensor.
| Brand | Pepperl Fuchs |
| Product Type | Proximity Sensor |
| Model Number | CJ10-30GM-WS |
Pepperl Fuchs CJ10-30GM-WS Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Switching function | Normally open (NO) |
| Output type | 2-wire |
| Rated operating distance | 10 mm |
| Installation | non-flush |
| Output polarity | AC |
| Assured operating distance | 0 ... 7.2 mm |
| Operating voltage | 20 ... 253 V AC1) |
| Switching frequency | 0 ... 10 Hz |
| Reverse polarity protection | reverse polarity tolerant |
| Short-circuit protection | - |
| Voltage drop | - |
| Operating current | 5 ... 200 mA |
| No-load supply current | - |
| Switching state indicator | LED, yellow |
| Ambient temperature | -25 ... 70 Β°C (-13 ... 158 Β°F) |
| Connection type | cable |
| Core cross section | - |
| Housing material | Stainless steel 1.4305 / AISI 303 |
| Sensing face | PBT |
| Degree of protection | IP67 |
| LED green | - |
| LED yellow | - |
| Storage temperature | -25 ... 85 Β°C (-13 ... 185 Β°F) |
| Mass | - |
