Omron WLCL-2-N Limit Switch
Omron WLCL-2-N Limit Switch uses an adjustable rod lever with a 25 to 140 mm range, screw terminals, and a G½ conduit size. The model is supplied without an operation indicator and has a listed pretravel of 25±5°. Electrical specifications include 25 mΩ max. initial contact resistance for the built-in switch, 100 MΩ min. insulation resistance at 500 VDC, and 50/60 Hz frequency. IP67 protection is specified together with an operating temperature range of -10 to +80°C with no icing and 35 to 95% RH. The WLCL-2-N belongs to the WL Series within the Omron Limit Switch range from Omron.
| Brand | Omron |
| Product | Limit Switch |
| Model Number | WLCL-2-N |
Omron WLCL-2-N Limit Switch – Technical Specifications
| Specification | Value |
|---|---|
| Terminal Shape | Screw terminals (Conduit size: G½) |
| Pretravel Pt | 25±5° |
| Indicator | Without operation indicator |
| Ambient Temperature | -10 to +80°C (with no icing) |
| Ambient Humidity | 35 to 95%RH |
| Shock Resistance | Destruction: 1,000 m/s2 min. Malfunction: 300 m/s2 min. |
| Degree Of Protection | IP67 |
| Insulation Resistance | 100 MΩ min. (at 500 VDC) |
| Actuator | Adjustable rod lever: (25 to 140 mm) |
| Vibration Resistance | Malfunction: 10 to 55 Hz, 1.5-mm double amplitude |
| Contact Resistance | 25 mΩ max. (initial value for the built-in switch) |
| Rated Frequency | 50/60 Hz |
The Omron WLCL-2-N Limit Switch uses an adjustable rod lever with a stated adjustment range from 25 to 140 mm. Its connection format is screw terminals with a G½ conduit size, and the model is supplied without an operation indicator. The listed pretravel is 25±5°. Electrical characteristics include 25 mΩ max. initial contact resistance for the built-in switch, 100 MΩ min. insulation resistance at 500 VDC, and 50/60 Hz frequency. These specifications identify the WLCL-2-N through the adjustable rod lever, terminal arrangement, conduit size, pretravel, indicator configuration, contact resistance, and insulation resistance. The 25 to 140 mm figure belongs to the adjustable rod lever specification, while 25±5° is the separate pretravel value stated for the model.
Environmental data for the WLCL-2-N includes IP67 protection, an operating temperature range of -10 to +80°C with no icing, and 35 to 95% RH. Malfunction vibration is specified at 10 to 55 Hz with 1.5 mm double amplitude. Shock values are 1,000 m/s² min. for destruction and 300 m/s² min. for malfunction. Together, these figures provide the listed enclosure, temperature, humidity, vibration, and shock characteristics without adding an application not stated in the source. For another WL Series adjustable-rod configuration, see the WLCL-N.
