Omron TL-W5MD1 2M Proximity Sensor
Omron TL-W5MD1 is a flat inductive, unshielded proximity sensor with a 5 mm sensing distance and a 0 to 4 mm setting distance. It uses a DC 2-wire NO output, a pre-wired 2 m cable, and a 12 to 24 VDC power supply. Ferrous metal is the specified detectable object, with an iron 18 × 18 × 1 mm standard sensing object. Response frequency is 500 Hz, control-output load current is 3 to 100 mA, and differential travel is 10% max. of sensing distance. Red and green indicators show operation and setting status. The TL-W5MD1 is listed under flat inductive proximity sensors from Omron industrial sensing products.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | TL-W5MD1 2M |
Omron TL-W5MD1 2M Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Flat Inductive |
| Sensing Distance | 5 mm |
| Setting Distance | 0 to 4 mm |
| Output Configuration | DC 2-Wire |
| Operation Mode | NO |
| Connection | Pre-wired 2 M Cable |
| Differential Travel | 10% max. of sensing distance |
| Detectable Object | Ferrous metal |
| Standard Sensing Object | Iron, 18 × 18 × 1 mm |
| Response Frequency | 500 Hz |
| Control Output Load Current | 3 to 100 mA |
| Indicator | Operation indicator (red), Setting indicator (green) |
| Protection Circuit | Load short-circuit protection, Surge suppressor |
| Ambient Temperature Range | Operating/Storage: −25 to 70°C (with no icing or condensation) |
| Ambient Humidity Range | Operating/Storage: 35% to 95% (with no condensation) |
| Material | Heat-resistant ABS |
| Degree Of Protection | IP67 |
| Weight | Approx. 80 g |
The Omron TL-W5MD1 2M Proximity Sensor uses a flat inductive, unshielded sensing arrangement with a 5 mm sensing distance and a 0 to 4 mm setting distance. Its output is DC 2-wire with NO operation, connected through a pre-wired 2 m cable and supplied from 12 to 24 VDC. Ferrous metal is specified as the detectable object, while the standard sensing object is iron measuring 18 × 18 × 1 mm. Response frequency is 500 Hz, control-output load current is 3 to 100 mA, and differential travel is 10% max. of sensing distance. A red operation indicator and green setting indicator are provided, together with load short-circuit protection and a surge suppressor.
Operating and storage temperature is specified from -25 to 70°C without icing or condensation, with humidity from 35% to 95%. Heat-resistant ABS is listed as the material, and the degree of protection is IP67. These values identify the model by its flat body, 5 mm unshielded sensing, DC 2-wire NO circuit, and 2 m connection. The switching specification therefore remains distinct from three-wire versions. For another TL-W model with the same 5 mm sensing distance and 2 m cable but a shielded DC 3-wire NPN NO configuration, see TL-W5E1 2M.
