Omron S8VS-48024B Power Supply
Omron S8VS-48024B SMPS is a 480 W switch mode power supply designed to provide 24 VDC with 20 A rated output current. It operates from 100 to 240 VAC input at 50/60 Hz and uses DIN rail mounting for structured electrical-cabinet installation. Screw terminals and terminal blocks provide fixed connections for the incoming AC supply and outgoing DC wiring. Typical efficiency is specified at 89% with 100 VAC input and 93% with 200 VAC input. A green output indicator provides operating status. Its 20 A output capacity places this model among the higher-current S8VS configurations. Within the S8VS Series, the S8VS-48024B provides a DIN rail 480 W, 24 VDC configuration. Compare other 20A industrial power supplies from Omron machine automation.

| Brand | Omron |
| Product | Power Supply |
| Model Number | S8VS-48024B |
Omron S8VS-48024B Power Supply - Technical Specifications
| Specification | Value |
|---|---|
| Power rating | 480 W |
| Output voltage | 24 VDC |
| Rated output current | 20 A |
| Terminal type | Screw Terminal |
| Mounting method | DIN rail |
| Connection | Terminal blocks |
| Efficiency | 89% typ. (at 100 VAC input) 93% typ. (at 200 VAC input) |
| Rated input voltage | 100 to 240 VAC |
| Rated input current | 7.4 A max., 5.8 A typ. (at 100 VAC input) 3.9 A max., 2.8 A typ. (at 200 VAC input) |
| Input Leakage current | 0.5 mA max. (at 100 VAC input) 1.0 mA max. (at 200 VAC input) |
| Input Frequency | 50/60Hz |
| Output indicator | Yes (color: green) |
| Output voltage variable range | -10 to +15% With V.ADJ |
| Start-up time | 550 ms typ. (at 100 VAC input) 550 ms typ. (at 200 VAC input) |
| Hold time | 37 ms typ. (at 100 VAC input) 41 ms typ. (at 200 VAC input) |
| Vibration resistance | 10 to 55 Hz, 0.375 mm single amplitude in each 3 directions for 2 hours |
| Shock resistance | 150 m/s2, in each 6 directions 3 times |
| Ambient temperature (Operating) | -10 to 60 ? |
| Ambient temperature (Storage) | -25 to 65 ? |
| Ambient humidity (OperatingStorage) | 25 to 85% |
| Cooling fan | No |
| Weight | 1700 g max. |
The Omron S8VS-48024B Power Supply provides 480 W rated power with a 24 VDC output and 20 A rated current. It accepts 100 to 240 VAC input at 50/60 Hz and uses DIN rail mounting with screw terminals and terminal blocks for electrical-cabinet installation. Typical efficiency is specified at 89% with 100 VAC input and 93% with 200 VAC input. These specifications define a high-current 24 VDC supply where connected load voltage, total current requirement, input compatibility, available rail space, and terminal access should be reviewed together. Connected equipment should require 24 VDC and keep continuous current demand within the rated 20 A output. The green output indicator provides a visible operating-status reference for panel checks. The fixed terminal arrangement provides input and output wiring points for integration with the panel circuit.
The same 480 W, 24 VDC, 20 A ratings are also available in another S8VS configuration, so comparison can focus on model variant rather than electrical capacity alone. When two models share the same output voltage, current rating, input range, and mounting format, model-specific configuration becomes the main distinction to verify. For another 480 W DIN rail configuration providing 24 VDC at 20 A, compare the Omron S8VS-48024A.
