The Omron S8VS-06024 Power Supply provides a 60 W DC source with a 24 VDC output rated at 2.5 A for industrial machine and control applications. It accepts 100 to 240 VAC at 50/60 Hz and converts the incoming AC supply into regulated DC power for compatible 24 VDC equipment. DIN rail mounting allows the power supply to be positioned with controllers, relays, terminals, and other electrical components inside a control cabinet, while screw terminals provide secure wiring connections. Its 60 W capacity offers additional output power compared with lower-wattage S8VS configurations for suitable control loads. The S8VS-06024 belongs to the S8VS Series and is categorized among 60W 24V power supplies from Omron automation equipment for industrial machine systems.
1.7 A max., 1.3 A typ. (at 100 VAC input)
1 A max., 0.68 A typ. (at 200 VAC input)
Input Leakage current
0.5 mA max. (at 100 VAC input)
1.0 mA max. (at 200 VAC input)
Input Frequency
50/60Hz
Output indicator
Yes (color: green)
Output voltage variable range
-10 to +15% With V.ADJ
Start-up time
620 ms typ. (at 100 VAC input)
400 ms typ. (at 200 VAC input)
Hold time
34 ms typ. (at 100 VAC input)
158 ms typ. (at 200 VAC input)
Vibration resistance
10 to 55 Hz, 0.375 mm single amplitude in each 3 directions for 2 hours
Shock resistance
150 m/s2, in each 6 directions 3 times
Ambient temperature (Operating)
-10 to 60 ?
Ambient temperature (Storage)
-25 to 65 ?
Ambient humidity (OperatingStorage)
25 to 85%
Cooling fan
No
Weight
330 g max.
The Omron S8VS-06024 is frequently evaluated with other models in the Omron Switch Mode Power Supply group, as these SMPS units share similar behaviour in thermal response, wiring layout, load handling, and rated input characteristics. Engineers often compare related models such as Omron S8VS-09024BP (90 W, 24 VDC, 100 to 240 VAC, 3.75 A, DIN rail), and Omron S8VS-12024BP (120 W, 24 VDC, 100 to 240 VAC, 5 A, DIN rail) when designing power rails for automation cabinets, motion drives, PLC racks, or distributed I/O stations. Analysing differences in power rating, output voltage behaviour, mounting format, rated input voltage, and continuous output current helps ensure voltage stability under diverse machine loads. The S8VS-06024 integrates smoothly into conveyors, dosing modules, electrical frames, and industrial panels where a dependable Omron SMPS Power Supply is required.
