Omron S8VK-G03005 Power Supply
The Omron S8VK-G03005 Power Supply is a 30 W industrial SMPS that converts supported input power into a 5 VDC output with 5 A rated current. It operates from 85 to 264 VAC or 90 to 350 VDC at 50/60 Hz, providing a regulated DC source for compatible low-voltage control equipment. DIN track mounting enables the unit to be positioned with other panel components, and rod terminals provide the required wiring connections. Its 5 VDC output makes this configuration suitable for industrial devices that require a lower DC supply voltage. The S8VK-G03005 belongs to the S8VK Series as a 30 W model. It can be compared with other 5V industrial power supplies available within Omron automation products for machine control applications.
| Brand | Omron |
| Product | Power Supply |
| Model Number | S8VK-G03005 |
Omron S8VK-G03005 Power Supply β Technical Specifications
| Specification | Value |
|---|---|
| Power rating | 30 W |
| Output voltage | 5 VDC |
| Rated output current | 5 A |
| Terminal type | Rod terminal |
| Mounting method | DIN track mounting |
| Construction | Covered type |
| Connection | Terminal blocks |
| Efficiency | 78% typ. (at 100 VAC input)79% typ. (at 200 VAC input) |
| Rated input voltage | 100 to 240 VAC |
| Rated input current | 0.6 A typ. (at 100 VAC input)0.35 A typ. (at 200 VAC input) |
| Input Leakage current | 0.5 mA max. (at 100 VAC input)1.0 mA max. (at 200 VAC input) |
| Input Frequency | 50/60Hz (47 to 450 Hz) |
| Output indicator | Yes (color: green, lighting from 80 to 90% or more of rated voltage) |
| Output voltage variable range | -10 to +15% With V.ADJ |
| Maximum peak current | 6 A |
| Start-up time | 600 ms typ. (at 100 VAC input)500 ms typ. (at 200 VAC input) |
| Hold time | 20 ms typ. (at 100 VAC input)110 ms typ. (at 200 VAC input) |
| Vibration resistance | 10 to 55 Hz, 0.375 mm Single amplitude in every 3 directions for 2 hours |
| Shock resistance | 150 m/s2, in each 6 directions 3 times |
| Ambient temperature (Operating) | -40 to 70 ? (with no freezing or condensation) |
| Ambient temperature (Storage) | -40 to 85 ? (with no freezing or condensation) |
| Ambient humidity (OperatingStorage) | 95% max. |
| Cooling fan | Cooling fan No |
| Degree of protection | IP20, EN/IEC 60529 |
| Weight (Main) | 195 g max. |
The Omron S8VK-G03005 is a Switch Mode Power Supply designed for stable DC power delivery in control panels and automation equipment. It belongs to the Omron SMPS family and is typically evaluated together with related models such as Omron S8VK-G01512 (15 W, 12 VDC, 1.2 A, Rod terminal, DIN track mounting), Omron S8VK-G01524 (15 W, 24 VDC, 0.65 A, Rod terminal, DIN track mounting), and Omron S8VK-C48024 (480 W, 24 VDC, 20A) when engineers are standardising their switch mode power supply lineup. Looking at power rating, output voltage, rated output current, terminal type, phase, and mounting method helps engineers choose the most suitable Omron SMPS Power Supply for each cabinet or machine section. The S8VK-G03005 integrates cleanly on DIN rails or inside enclosures, feeding PLCs, I/O modules, sensors, and safety relays where a reliable Omron Switch Mode Power Supply with predictable protection and wiring behaviour is required in continuous industrial service.
