Omron NX-OD2154 Machine Automation Controller
The Omron NX-OD2154 Machine Automation Controller is a 2-point Transistor Output Unit (NPN type) designed for compact high-speed digital output control. Supporting 24 VDC rated voltage, it provides 0.5 A/point, 1 A/unit load capacity. With an ultra-fast ON/OFF response time of 300 ns max., it supports Output Refreshing with specified time-stamp mode for precise event-based control. This unit is ideal for applications requiring deterministic output switching. Manufactured by Omron, part of the Omron Programmable Logic Controller (PLC) family, available under the Omron NX Series.
| Brand | Omron |
| Product Type | Machine Automation Controllers |
| Model Number | NX-OD2154 |
Omron NX-OD2154 Machine Automation Controller - Technical Specifications
| Specification | Value |
|---|---|
| Product name | Transistor Output Unit |
| I/O system | NX I/O Bus |
| Type of module | Digital I/O |
| Digital input type | None |
| Rated input voltage | 24 VDC |
| Number of digital outputs | 2 |
| Digital output type | NPN |
| Output current | 0.5 A |
| Connection method | 2-wire, 3-wire |
| Signal processing | High speed, Timestamp |
| I/O connection type | Push-in |
| Number of I/O connectors | 1 |
| ON response time | 300 ns max. |
| OFF response time | 300 ns max. |
| Degree of protection (IP) | IP20 |
| Product Weight (unpacked) | 65 g |
Talk to Our Engineer for Omron PLC 1 A/NX Unit NX-OD2154 with exclusive offers. Core System Specifications of NX-OD2154 are 2 points with internal I/O common NPN and operates on a rated input voltage of 24 VDC. It supports both Output refreshing with specified time stamp only methods, with an ON/OFF response time of 300 ns max. The unit's dimensions are 72 Γ 100 Γ 90 mm (WΓHΓD), and it requires a power supply voltage of 24 VDC (20.4 to 28.8 VDC) with a maximum power consumption of 5.80 W max. It also meets noise immunity standards of 2 kV on power supply line (Conforms to IEC 61000-4-4.) and has a pollution degree of 2 or less: Meets IEC 61010-2-201. The ambient operating temperature ranges from 0 to 55Β°C, with humidity from 10% to 95% (with no condensation), and storage temperatures from -25 to 70Β°C (excluding battery).Don't Miss Out on a Quote for your requirement of Omron PLC 1 A/NX Unit.
