Omron NX-ID3443 Machine Automation Controller
The Omron NX-ID3443 Machine Automation Controller is a robust Digital Input Unit offering 4 PNP input points with advanced Synchronous and Free-Run refreshing capabilities. Designed for precision motion and high-speed equipment, it provides a rapid 100 ns ON/OFF response at 24 VDC. Its dual refresh modes ensure flexible alignment with machine cycles while maintaining stable detection. Powered by 20.4β28.8 VDC with 5.80 W consumption, it fits demanding industrial applications. Manufactured by Omron, part of the Omron Programmable Logic Controller (PLC) range, available under the Omron NX Series.
| Brand | Omron |
| Product Type | Machine Automation Controllers |
| Model Number | NX-ID3443 |
Omron NX-ID3443 Machine Automation Controller - Technical Specifications
| Specification | Value |
|---|---|
| Number of Model points | 4 points |
| Internal I/O common | PNP |
| Rated input voltage | 24 VDC |
| I/O refreshing method | Switching Synchronous I/O refreshing and, Free-Run refreshing |
| ON/OFF response time | 100 ns max./100 ns max |
| Dimensions (mm) | 72 Γ 100 Γ 90 mm (WΓHΓD) |
| Power supply voltage | 24 VDC (20.4 to 28.8 VDC) |
| Unit power consumption | 5.80 W max. |
| Shock resistance | Conforms to IEC 60068-2-27. 147 m/s2, 3 times in X, Y, and Z directions |
| Vibration resistance | Conforms to IEC 60068-2-6. 5 to 8.4 Hz with 3.5-mm amplitude, 8.4 to 150 Hz, acceleration of 9.8 m/s2, 100 min each in X, Y, and Z directions (10 sweeps of 10 min each = 100 min total). |
| Noise immunity | 2 kV on power supply line (Conforms to IEC 61000-4-4.) |
| Pollution degree | 2 or less: Meets IEC 61010-2-201. |
| Ambient operating temperature | 0 to 55Β°C |
| Ambient operating humidity | 10% to 95% (with no condensation) |
| Ambient storage temperature | -25 to 70Β°C (excluding battery) |
| Weight | 390 g max. |
