Omron H5CC-L8ED Timer
The Omron H5CC-L8ED Timer is a reliable Digital timing solution designed for accurate control in modern industrial systems. It supports DIN rail, On-panel, Socket installation, ensuring flexibility for both new setups and panel replacements. Built in a compact 1/16 DIN (48 x 48 mm) format with an 8-pin Plug-in terminal layout, it delivers simple mounting and quick maintenance. As a Digital Timer, it offers a Multi-functional operating structure, equipped with an 2 x SPDT Relay outputfor reliable switching. Operating on 24-24 VAC and 12-48 VDC, it also provides compatible reset and signal inputs for seamless integration. Manufactured by Omron and available under Omron Timers, this model is part of the trusted H5CC Series.
| Brand | Omron |
| Product Type | Timers |
| Model Number | H5CC-L8ED |
Omron H5CC-L8ED Timer - Technical Specifications
| Specification | Value |
|---|---|
| Type | Digital |
| Installation type | DIN rail, On-panel, Socket |
| Functions | Multi-functional |
| Size | 1/16 DIN (48 x 48 mm) |
| Terminal type | Plug-in |
| Operating mode | Flicker OFF Start (Power ON Start), Flicker ON Start (Power ON Start), Interval (Signal Start), ON Delay (Power ON Start) |
| Output type | Relay |
| Contact description | 2 x SPDT |
| Supply voltage AC | 24-24 V |
| Supply voltage DC | 12-48 V |
| Number of pin contact | 8 |
| Features | Instantaneous contact |
The Omron H5CC-L8ED is a versatile digital timer engineered for flexible and accurate timing control in industrial equipment. With a 1/16 DIN (48 Γ 48 mm) size and plug-in 8-pin socket design, it ensures quick mounting on DIN rails or panels.
This model features 2 independent SPDT relay outputs and supports various operating modes including ON delay, interval, flicker ON, and flicker OFFβall with power-on start or signal-based control. Its bright digital display allows easy setting and status monitoring, while its multi-voltage DC input (12β48 VDC) ensures compatibility across diverse electrical systems.
Suitable for control panels, automation systems, and machinery requiring timed operations, the H5CC-L8ED offers reliable switching and precise timing. Its compact form factor, socket-ready installation, and support for multiple functions make it a dependable solution for time-based automation tasks in industrial settings.
