Omron GI-SID1224 Safety Controller
The Omron GI-SID1224 Safety Controller is a safety I/O terminal from the GI-SID Series, optimized for EtherNet/IP applications requiring decentralized safety input processing. Featuring two connectors and network variable mapping of 1-to-1, it provides 12 safety input points and 12 test outputs. Housed in an open-type, panel-mounted enclosure, it meets Class III SELV and pollution degree 2 requirements while operating from 0 to 55°C with broad humidity tolerance. IEC-certified vibration and shock resistance enhance durability. Manufactured by Omron and part of Omron Safety Controller, it integrates into the GI-SID Series.
| Brand | Omron |
| Product Type | Safety Controller |
| Model Number | GI-SID1224 |
Omron GI-SID1224 Safety Controller - Technical Specifications
| Specification | Value |
|---|---|
| Unit type | Safety I/O Terminals |
| Supported communications protocol | EtherNet/IP |
| Number of communications connectors | 2 |
| Network variables | 1,1 |
| Number of safety input points | 12 points |
| Number of test output point | 12 points |
| Enclosure | Mounted in a panel (open type) |
| Ambient operating temperature | 0 to 55°C |
| Ambient operating humidity | 10% to 95% (with no condensation or icing) |
| Ambient storage temperature | −25 to 70°C (with no condensation or icing) |
| Pollution degree | 2 |
| Insulation class | Class III (SELV) |
| Vibration resistance | Conforms to IEC 60068-2-6. 5 to 8.4 Hz with 3.5-mm amplitude 8.4 to 150 Hz, acceleration of 9.8 m/s2 100 minutes each in X, Y, and Z directions (10 sweeps of 10 min each = 100 min total) |
| Shock resistance | Conforms to IEC 60068-2-27. 147 m/s2 , 3 times each in X, Y, and Z directions |
| Insulation resistance | 20 MΩ between isolated circuits (at 100 VDC) |
| Dielectric strength | 500 VAC between isolated circuits for 1 minute at a leakage current of 10 mA max. |
| Installation method | DIN Track (IEC 60715 TH35-7.5/TH35-15) |
| Degree of protection | IP20 |
The GI-SID1224 from Omron provides 12 dedicated safety input points and 12 test output points, making it ideal for distributed safety architectures. It supports EtherNet/IP with 2 communication connectors and uses a screwless push-in terminal design, simplifying panel wiring. With DIN rail mounting compatibility per IEC 60715, installation is both efficient and secure.
Engineered to perform under challenging industrial conditions, this Safety I/O Terminal operates at ambient temperatures from 0 to 55°C and humidity levels between 10% to 95% without condensation. It meets Class III SELV insulation standards and conforms to IEC 60068-2 for vibration and shock resistance. With a pollution degree 2 rating and IP20 protection, the GI-SID1224 ensures lasting performance and system integrity.
Built with Omron’s trusted safety technology, the GI-SID1224 is a dependable choice for engineers seeking robust safety signal acquisition and control.
