Omron G3PE-225B-3N DC12-24 Solid-state Relay
Omron G3PE-225B-3N DC12-24 is a three-phase G3PE solid state relay built with three elements and phototriac isolation. Its electrical input is rated from 12 to 24 VDC and the input operating range extends from 9.6 to 30 VDC. On the output side, the relay is rated for 100 to 240 VAC with a 75 to 264 VAC load voltage range and 25 A load current at 40°C. Output inrush current resistivity is 220 A for one 60 Hz cycle. DIN track mounting, screw terminals, an equipped zero-cross function, and a yellow operating indicator are specified. The G3PE-225B-3N DC12-24 belongs to the G3PE series under the SSR range from Omron relay components.
| Brand | Omron |
| Product | Solid State Relay |
| Model Number | G3PE-225B-3N DC12-24 |
Omron G3PE-225B-3N DC12-24 Solid-state Relay - Technical Specifications
| Specification | Value |
|---|---|
| Number Of Phases | Three phase |
| Isolation Method | Phototriac |
| Mounting | DIN track mounting |
| Operating Indicator | Equipped (Yellow) |
| Terminal Structure | Screw terminal |
| Product Classification | For 3-phase Heater |
| Number Of Elements | 3 |
| Zero Cross Function | Equipped |
| Input Rated Voltage | 12 to 24 VDC |
| Input Current | 10 mA max. (at 24 VDC) |
| Input Operate Voltage | 9.6 VDC max. |
| Input Release Voltage | 1 VDC min. |
| Output Rated Load Voltage | 100 to 240 VAC |
| Output Load Voltage Range | 75 to 264 VAC |
| Output Minimum Load Current | 0.2 A |
| Output Load Current | 25 A (at 40 ℃) |
| Output Inrush Current Resistivity | 220 A (60 Hz 1 cycle) |
| Operate Time | 1/2 cycle of load power source + 1 ms max. |
| Release Time | 1/2 cycle of load power source + 1 ms max. |
| Output On Voltage Drop | 1.6 V max. (RMS) |
| Leakage Current | 10 mA max. (at 200 VAC) |
| Insulation Resistance | 100 MΩ min. (at 500 VDC) |
| Dielectric Strength | 2500 VAC 50/60 Hz 1 min |
| Vibration Resistance | 10 to 55 to 10 Hz, 0.175 mm single amplitude (0.35 mm double amplitude) |
| Shock Resistance | 294 m/s 2 (98 m/s 2 with reverse mounting) |
| Ambient Temperature Operating | -30 to 80 ℃ (with no freezing or condensation) |
| Ambient Temperature Storage | -30 to 100 ℃ (with no freezing or condensation) |
| Ambient Humidity Operating | 45 to 85% RH |
| Weight | Approx. 1250 g |
The Omron G3PE-225B-3N DC12-24 Solid State Relay combines a three-phase configuration with three elements, phototriac isolation, DIN track mounting, and screw terminals. Its rated input range is 12 to 24 VDC and the input operating range is 9.6 to 30 VDC. At 24 VDC, input current is specified as 10 mA max.; input operate voltage is 9.6 VDC max. and release voltage is 1 VDC min. Output rated load voltage is 100 to 240 VAC, with a 75 to 264 VAC load voltage range. The relay carries a 25 A load-current rating at 40°C and 220 A output inrush current resistivity for one 60 Hz cycle. A yellow operating indicator and equipped zero-cross function are included in the supplied specifications.
Operate and release times each equal one-half cycle of the load power source plus 1 ms max. Output ON voltage drop is 1.6 V max. RMS, and leakage current is listed as 10 mA max. at 200 VAC. Insulation resistance is 100 MΩ min. at 500 VDC, accompanied by 2500 VAC dielectric strength at 50/60 Hz for 1 minute. The specified operating-temperature range is -30 to 80°C without freezing or condensation. A related 25 A G3PE entry with two elements and a 25°C load-current rating is the G3PE-225B DC12-24.
