Omron F3SJ-E0785P25 Safety Light Curtain
Omron F3SJ-E0785P25 is a Safety Light Curtain designed for 25 mm hand protection across a 785 mm protective height. Its sensing field contains 38 infrared beams arranged with a 20 mm beam gap to detect opaque objects entering the protected access area. The operating range extends from 0.2 to 7 m, while the unit operates from a SELV/PELV 24 VDC supply. PNP transistor outputs provide the electrical interface for the machine safety system. Within the F3SJ Series, the F3SJ-E0785P25 combines 25 mm detection with 785 mm vertical coverage. For different protective field dimensions, compare extended hand protection light curtains available through Omron safety automation products.
| Brand | Omron |
| Product | Safety Light Curtain |
| Model Number | F3SJ-E0785P25 |
Omron F3SJ-E0785P25 Safety Light Curtain - Technical Specifications
| Specification | Value |
|---|---|
| Application | Hand protection |
| Object Resolution | Opaque objects |
| Detection Capability | 25 mm dia. |
| Beam Gap | 20 mm |
| Number Of Beams | 38 Beams |
| Protective Height | 785 mm |
| Lens Size | 5 mm |
| Operating Range | 0.2 to 7 m |
| Light Source | Infrared LED (870 nm) |
| Startup Waiting Time | 2 s max. |
| Power Supply Voltage | SELV/PELV 24 VDC±20% (ripple p-p 10% max.) |
| Current Consumption | Emitter: 57 mA max.; Receiver: 47 mA max. |
| Safety Outputs Ossd | Two PNP transistor outputs, load current 200 mA max., residual voltage 2 V max. (except for voltage drop due to cable extension), Leakage current 1 mA max., load inductance 2.2 H max. *3, Maximum capacity load 1 ?F |
| Protective Circuit | Output short-circuit protection, and power supply reverse polarity protection |
| Insulation Resistance | 20 M? min. (at 500 VDC) |
| Ambient Temperature | Operating: -10 to 55°C (non-freezing), Storage: -25 to 70°C |
| Ambient Humidity | Operating: 35% to 85% (no condensation), Storage: 35% to 95% RH |
| Degree Of Protection | IP65 (IEC 60529) |
| Materials | Case: Aluminum Cap: ABS resin, PBT Optical cover: PMMA resin (acrylic) Cable: Oil resistant PVC |
The Omron F3SJ-E0785P25 Safety Light Curtain provides 25 mm hand detection across a 785 mm protective height. Its sensing field contains 38 infrared beams arranged with a 20 mm beam gap to detect opaque objects entering the protected machine opening. The operating range extends from 0.2 to 7 m, while the unit operates from a SELV/PELV 24 VDC ±20% supply. Two PNP transistor outputs support maximum load currents of 200 mA each. Output short-circuit and power-supply reverse-polarity protection are specified, while the enclosure carries an IP65 protection rating and supports operation from -10 to 55°C.
For model selection, the F3SJ-E0785P25 should be assessed by its 25 mm detection capability, 785 mm protective height, 20 mm beam spacing, PNP output type, and sensing range. These values define the hand-protection field and electrical interface of the safety system. The supplied comparison model also provides hand protection but uses a closer 15 mm beam gap, 62 beams, and a 935 mm protective height. For that configuration, see Omron F3SJ-A0935P20.
