Omron F3SP-B1P Safety Light Curtain
Omron F3SP-B1P is a Safety Control Unit designed to interface safety light curtain signals with machine safety circuits. It provides 3PST-NO main contacts, one SPST-NC auxiliary contact, and one PNP light curtain auxiliary output for the specified control arrangement. The unit operates from a 24 VDC supply with a rated voltage tolerance of -15% to +10% and consumes up to 1.7 W. Its operating time is 100 ms maximum, while the listed response time is 10 ms maximum. Within the F3SP Series, the F3SP-B1P provides the stated contact and auxiliary output configuration. For related safety system components, explore machine safety light curtain products available through Omron safety control products.
| Brand | Omron |
| Product | Safety Light Curtain |
| Model Number | F3SP-B1P |
Omron F3SP-B1P Safety Light Curtain - Technical Specifications
| Specification | Value |
|---|---|
| Main Contacts | 3PST-NO |
| Auxiliary Contact | SPST-NC |
| Light Curtain Auxiliary Output | 1PNP |
| Rated Voltage | 1.7 W max |
| Operating Voltage Range | -15% to +10% of rated supply voltage |
| Power Consumption | 24 VDC |
| Operating Time | 100 ms max |
| Response Time | 10 ms max |
| Vibration Resistance | 10 to 55 Hz 0.35 mm single amplitude (0.7 mm double amplitude) |
| Shock Resistance | Destruction 300 m/s2 Malfunction 100 m/s2 |
| Ambient Operating Temperature | -10 to 55°C |
| Ambient Operating Humidity | 35 to 85% RH |
The Omron F3SP-B1P Safety Control Unit provides a 3PST-NO main contact configuration, one SPST-NC auxiliary contact, and one PNP light curtain auxiliary output. It operates from a 24 VDC supply with a rated voltage tolerance of -15% to +10% and has a maximum power consumption of 1.7 W. The specified operating time is 100 ms maximum, while the listed response time is 10 ms maximum. Its vibration specification is 10 to 55 Hz with 0.35 mm single amplitude, and the operating temperature range is -10 to 55°C with 35% to 85% relative humidity. The listed shock resistance is 300 m/s² for destruction and 100 m/s² for malfunction.
For selection, the F3SP-B1P should be evaluated by its 3PST-NO main contacts, SPST-NC auxiliary contact, PNP light curtain auxiliary output, 24 VDC supply, operating time, and response time. These are the source-supported electrical and control characteristics for this unit, and they should be checked together when matching the controller to the required contact arrangement. The supplied comparison data includes cable and connector products carrying similar contact descriptions, so those related products should not be treated as direct controller equivalents without checking their specific functions. Where an emitter-side M12 connection and 0.3 m cable length are required in the supplied comparison set, see Omron F39-JGR3M-B58-L.
