Omron EE-SY671 Photomicrosensor
The Omron EE-SY671 Photomicrosensor offers Reflective, Horizontal type, 1 to 5 mm Sensing distance, NPN Output, Connector (4 poles), 5 to 24 VDC Power supply voltage, Dark-ON/Light-ON mode. Manufactured by Omron under the Omron Photoelectric Sensors category, this model belongs to the Omron EE Series.
| Brand | Omron |
| Product Type | Photomicrosensor |
| Model Number | EE-SY671 |
Omron EE-SY671 Photomicrosensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Horizontal type |
| Luminous method | Non-modulated |
| Sensing method | Reflective |
| Sensing distance | 1 to 5 mm |
| Control output (Output type) | NPN |
| Control output (Residual voltage) | at 100 mA load current: 0.8 V max. at 40 mA load current: 0.4 V max. |
| Operation mode | Dark-ON/Light-ON |
| Connection method | Connector (4 poles) |
| Current consumption | 40 mA |
| Control output (Load current) | 100 mA max. |
| Indicator | Light indicator (red) |
| Power supply voltage | 5 to 24 VDC |
| Material | Case: Polybutylene terephthalate (PBT) Emitter/Receiver: Polycarbonate (PC) |
| Degree of protection | IP50 |
| Ambient temperature (Operating) | -25 to 55 β |
| Ambient temperature (Storage) | -30 to 80 β |
| Ambient humidity (Operating) | 5 to 85 % |
| Ambient humidity (Storage) | 5 to 95 % |
| Shock resistance | Destruction: 500 m/s2 for 3 times each in X, Y, and Z directions |
| Vibration resistance | Destruction: 20 to 2000 Hz, peak acceleration 100 m/s2, 1.5-mm double amplitude 2 h each in X, Y, and Z directions (4 min periods) |
The Omron EE-SY671 is a compact reflective photomicrosensor designed for short-range detection in tight industrial setups. Its horizontal form factor makes it suitable for mounting in narrow spaces, while the reflective sensing method ensures detection at distances between 1 and 5 mm.
This sensor features a selectable Light-ON/Dark-ON mode and delivers an NPN open collector output, making it flexible for a wide range of control circuits. It consumes just 40 mA and supports up to 100 mA load current. A red LED indicator provides visual feedback during operation. The connector-type interface enables quick and clean installations.
Housed in a durable PBT body with PC emitter and receiver covers, the EE-SY671 is built to withstand vibrations and shock. It is rated IP50 and operates in ambient temperatures from -25Β°C to 55Β°C. Ideal for object detection on conveyors, labeling systems, or packaging lines.
