Omron EE-SX971-C1 Photomicrosensor
The Omron EE-SX971-C1 Photomicrosensor offers Throughbeam with slot, L-shaped, 5 mm Sensing distance, NPN Output, Connector (4 poles), 5 to 24 VDC Power supply voltage, With both Dark-ON and Light-ON mode. Manufactured by Omron under the Omron Photoelectric Sensors category, this model belongs to the Omron EE Series.
| Brand | Omron |
| Product | Photomicro Sensors |
| Model Number | EE-SX971-C1 |
Omron EE-SX971-C1 Photomicrosensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | L-shaped |
| Sensing Method | Throughbeam with slot |
| Sensing Distance | 5 mm |
| Power Supply Voltage | 5 to 24 VDC |
| Control Output (Output Type) | NPN |
| Connection Method | Connector (4 poles) |
| Current Consumption | 21 mA |
| Operation Mode | With both Dark-ON and Light-ON |
| Control Output (Residual Voltage) | at 5 mA load current: 0.4 V max. at 50 mA load current: 1.0 V max. |
| Control Output (Load Current) | 50 mA max. |
| Indicator | Light indicator (orange) |
| Luminous Method | Non-modulated |
| Ambient Temperature (Operating) | -25 to 55 β (with no freezing or condensation) |
| Ambient Temperature (Storage) | -30 to 80 β (with no freezing or condensation) |
| Ambient Humidity (Operating) | 5 to 85 % (with no freezing or condensation) |
| Ambient Humidity (Storage) | 5 to 95 % (with no freezing or condensation) |
| Vibration Resistance | Destruction: 10 to 2000 Hz, 0.75 mm single amplitude in each X, Y, and Z directions (15 min, 10 cycle) |
| Shock Resistance | Destruction: 500 m/s2 for 3 times each in X, Y, and Z directions |
| Degree Of Protection | IP50 |
| Material | Case: Polybutylene terephthalate (PBT) Cover: Polybutylene terephthalate (PBT) Emitter/Receiver: Polycarbonate (PC) |
The Omron EE-SX971-C1 is a compact L-shaped slot-type photomicrosensor designed for precise object detection across a 5 mm slot width. Its connector-type interface and grooved form factor make it easy to integrate into tight automation environments.
This model provides two independent NPN open collector outputsβsupporting both Light-ON and Dark-ON detectionβmaking it versatile for different logic requirements. With a low current consumption of 21 mA and a visible orange LED for status indication, it ensures both energy efficiency and ease of maintenance.
Built with high-durability PBT and PC materials, the EE-SX971-C1 performs reliably under demanding conditions, including temperatures from -25Β°C to 55Β°C. With a response-ready design and high shock/vibration resistance, it is ideal for applications like object counting, presence sensing, and part confirmation in compact systems.
