Omron EE-SX951-R 1M Photomicrosensor
The Omron EE-SX951-R 1M Photomicrosensor offers Throughbeam with slot, L-shaped, 5 mm Sensing distance, NPN Output, Pre-wired model with robot cable 1 m, 5 to 24 VDC Power supply voltage, With both Dark-ON and Light-ON mode. Manufactured by Omron under the Omron Photoelectric Sensors category, this model belongs to the Omron EE Series.
| Brand | Omron |
| Product | Photomicro Sensors |
| Model Number | EE-SX951-R 1M |
Omron EE-SX951-R 1M Photomicrosensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | L-shaped |
| Sensing Method | Throughbeam with slot |
| Sensing Distance | 5 mm |
| Power Supply Voltage | 5 to 24 VDC |
| Control Output (Output Type) | NPN |
| Connection Method | Pre-wired model with robot cable 1 m |
| Cable Length | 1 m |
| Current Consumption | 15 mA |
| Operation Mode | With both Dark-ON and Light-ON |
| Control Output (Residual Voltage) | at 50 mA load current: 0.7 V max. at 5 mA load current: 0.4 V max. |
| Control Output (Load Current) | 50 mA max. |
| Indicator | Light indicator (red) |
| Luminous Method | Non-modulated |
| Ambient Temperature (Operating) | -25 to 55 β |
| Ambient Temperature (Storage) | -30 to 80 β |
| Ambient Humidity (Operating) | 5 to 85 % |
| Ambient Humidity (Storage) | 5 to 95 % |
| Vibration Resistance | Destruction: 10 to 2000 Hz, peak acceleration 150 m/s2, 0.75 mm single amplitude 2.5 h each in X, Y, and Z directions (15 min periods, 10 cycle) |
| Shock Resistance | Destruction: 500 m/s2 for 3 times each in X, Y, and Z directions |
| Degree Of Protection | IP50 |
| Material | Case: Polybutylene terephthalate (PBT) Cover: Polybutylene terephthalate (PBT) Emitter/Receiver: Polycarbonate (PC) |
The Omron EE-SX951-R 1M is an L-shaped grooved photomicrosensor featuring a 5 mm slot width, designed for reliable object detection in compact spaces. With a non-modulated through-beam sensing method, it ensures consistent performance in various industrial applications.
This model offers NPN open collector outputs that support both Light-ON and Dark-ON modes, giving users flexible logic control. The sensor includes a red LED indicator for visual operation feedback and consumes only 15 mA of current, making it energy-efficient. Its 1 m robotic-grade pre-wired cable supports motion-intensive setups.
Encased in PBT and PC materials, the EE-SX951-R is IP50 rated and built to endure shock and vibration. It operates reliably in environments ranging from -25Β°C to 55Β°C, making it suitable for applications like part detection, slot monitoring, and compact automation machinery.
