Omron EE-SX772A 2M Photomicrosensor
The Omron EE-SX772A 2M Photomicrosensor offers T-shaped, Through-beam with slot, 5 mm Sensing distance, NPN Output, Pre-wired 2 M Cable, GaAs infrared LED (940 nm), 5 to 24 VDC Power supply voltage, Dark-ON mode. Manufactured by Omron under the Omron Photoelectric Sensors category, this model belongs to the Omron EE Series.
| Brand | Omron |
| Product Type | Photomicro Sensor |
| Model Number | EE-SX772A 2M |
Omron EE-SX772A 2M Photomicrosensor β Technical Specifications
| Specification | Value |
|---|---|
| Appearance | T-shaped |
| Sensing Method | Through-beam with slot |
| Sensing Distance | 5 mm |
| Standard Sensing Object | Opaque, 2 x 0.8 mm min. |
| Light Source | GaAs infrared LED (940 nm) |
| Power Supply Voltage | 5 to 24 VDC |
| Output configuration | NPN |
| Connection Method | Pre-wired 2 M Cable |
| Current Consumption | 12 mA max. |
| Operation Mode | Dark-ON |
| Indicators | No incident light (red) |
| Ambient Temperature Range | Operating: -25 to 55 β (with no icing) Storage: -30 to 80 β (with no icing) |
| Ambient Humidity Range | Operating: 5 to 85 % (with no condensation) Storage: 5 to 95 % (with no condensation) |
| Vibration Resistance | Destruction: 10 to 2000 Hz, peak acceleration 100 m/s2, 1.5-mm double amplitude 2 h each in X, Y, and Z directions (4 min periods) |
| Shock Resistance | Destruction: 500 m/s2 for 3 times each in X, Y, and Z directions |
| Protection Circuits | Output short-cut protection |
| Degree of Protection | IP64 IEC60529 |
| Material | Case: Polybutylene terephthalate (PBT) |
| Weight | Package: Approx. 20 g |
Omron is a trusted global leader in industrial sensing solutions, known for its reliable and space-efficient sensors. The Omron EE-SX772A 2M belongs to its high-performance photomicrosensor lineup and offers a slim and compact design tailored for precision automation. Designed with built-in amplification and robust circuitry, the EE SX772A 2M delivers reliable performance in demanding factory conditions, making it a preferred choice among engineers for tight-mounting environments.
The Omron EE-SX772A 2M uses a through-beam slot-type sensing method with a 5 mm slot width. It operates at 5 to 24 VDC and uses a 940 nm infrared GaAs LED light source. Featuring a Dark-ON output mode with NPN output, it has a red LED indicator when no light is detected. With protection circuits, 12 mA low power consumption, and IP64 housing made of durable PBT, itβs built for industrial durability.
With its high vibration and shock resistance, the EE SX772A 2M is well-suited for use in label detection, slot sensing, and conveyor-based automation. Its small footprint and rugged cable design make it suitable for robotics and compact assembly lines. For engineers requiring consistent and interference-free performance in tight setups, the Omron EE-SX772A 2M is a proven Omron Photomicrosensor with Slim Cable.
