Omron EE-SX677P Photomicrosensor
Omron EE-SX677P is an R-shaped through-beam slot photomicrosensor designed with a fixed 5 mm sensing gap and a PNP output. An infrared LED forms the internal optical path between the emitter and receiver, while the output state changes as a target passes through the sensing opening. Light-ON or Dark-ON operation can be selected to match the required control logic. The sensor operates from 5 to 24 VDC and consumes 12 mA maximum. A 4-pole connector provides the electrical interface, while load short-circuit protection supports the output circuit. For compact R-shaped sensing with PNP switching, the EE-SX677P belongs to the slot-type optical sensor range developed across Omron Industrial Sensors.
| Brand | Omron |
| Product | Photomicro Sensors |
| Model Number | EE-SX677P |
Omron EE-SX677P Photomicrosensor – Technical Specifications
| Specification | Value |
|---|---|
| Appearance | R-shaped |
| Sensing Method | Throughbeam with slot |
| Sensing Distance | 5 mm |
| Light Source | Infrared LED |
| Power Supply Voltage | 5 to 24 VDC |
| Output Configuration | PNP |
| Connection Method | Connector (4 poles) |
| Current Consumption | 12 mA max. |
| Operation Mode | Dark-ON/ Light-ON (selectable) |
| Indicators | Incident light |
| Ambient Illumination | 1,000 lx max. with fluorescent light on the surface of the receiver |
| Ambient Temperature Range | Operating: −25 to +55°C, Storage: −30 to +80°C (with no icing or condensation) |
| Ambient Humidity Range | Operating: 5% to 85%, Storage: 5% to 95% (with no icing or condensation) |
| Vibration Resistance | Destruction: 20 to 2,000 Hz (peak acceleration: 100 m/s2) 1.5-mm double amplitude for 2 h (4-min periods) each in X, Y, and Z directions |
| Shock Resistance | Destruction: 500 m/s2 for 3 times each in X, Y, and Z directions |
| Protection Circuits | Load short circuit protection |
| Degree Of Protection | IEC60529 IP50 |
| Material | Polybutylene phthalate (PBT) |
The Omron EE-SX677P Photomicrosensor uses an R-shaped through-beam slot arrangement with a fixed 5 mm sensing gap and a PNP output. An infrared LED establishes the internal optical path across the slot, while the output state changes according to the target condition as a component passes through the opening. Light-ON or Dark-ON operation can be selected to match the required control sequence. The unit operates from 5 to 24 VDC and consumes 12 mA maximum. A 4-pole connector provides the electrical interface, and load short-circuit protection supports the output circuit. Fluorescent-light resistance is specified up to 1,000 lx on the receiver surface under the stated ambient-light conditions.
The EE-SX677P uses a PBT body and is specified for operation from -25°C to 55°C, while storage extends from -30°C to 80°C. The listed mechanical ratings include vibration from 20 to 2,000 Hz and shock resistance of 500 m/s² under the stated test procedures. IP50 protection is specified for the enclosure. Its R-shaped geometry provides the same basic mounting form as the EE-SX677, but this model uses PNP switching instead of NPN. That distinction makes the model relevant where the connected control circuitry requires a PNP signal. For the corresponding R-shaped connector model with an NPN output, see the Omron EE-SX677.
