Omron EE-SX677 Photomicrosensor
The Omron EE-SX677 Photomicrosensor offers R-shaped, Throughbeam with slot, 5 mm Sensing distance, NPN Output, Connector (4 poles), Infrared LED, 5 to 24 VDC Power supply voltage, Dark-ON/ Light-ON (selectable) mode. Manufactured by Omron under the Omron Photoelectric Sensors category, this model belongs to the Omron EE Series.
| Brand | Omron |
| Product Type | Photomicro Sensor |
| Model Number | EE-SX677 |
Omron EE-SX677 Photomicrosensor β Technical Specifications
| Specification | Value |
|---|---|
| Appearance | R-shaped |
| Sensing Method | Throughbeam with slot |
| Sensing Distance | 5 mm |
| Light Source | Infrared LED |
| Power Supply Voltage | 5 to 24 VDC |
| Output configuration | NPN |
| Connection Method | Connector (4 poles) |
| Current Consumption | 12 mA max. |
| Operation Mode | Dark-ON/ Light-ON (selectable) |
| Indicators | Incident light |
| Ambient Illumination | 1,000 lx max. with fluorescent light on the surface of the receiver |
| Ambient Temperature Range | Operating: β25 to +55Β°C, Storage: β30 to +80Β°C (with no icing or condensation) |
| Ambient Humidity Range | Operating: 5% to 85%, Storage: 5% to 95% (with no icing or condensation) |
| Vibration Resistance | Destruction: 20 to 2,000 Hz (peak acceleration: 100 m/s2) 1.5-mm double amplitude for 2 h (4-min periods) each in X, Y, and Z directions |
| Shock Resistance | Destruction: 500 m/s2 for 3 times each in X, Y, and Z directions |
| Protection Circuits | Load short circuit protection |
| Degree of Protection | IEC60529 IP50 |
| Material | Polybutylene phthalate (PBT) |
Omron is globally recognized for designing high-performance sensors that offer precise, compact, and durable solutions for industrial automation. The Omron EE-SX677 is part of their trusted photo micro sensor lineup, featuring an R-shaped design with a narrow sensing slot. Built for machine builders and OEMs, the EE SX677 ensures stable detection in tight environments. Its rugged construction, excellent signal clarity, and repeatable performance make it a dependable Omron R-Shaped Photo Micro Sensor.
The Omron EE-SX677 operates on a throughbeam principle with a 5 mm slot width and emits infrared light (940 nm) for accurate object sensing. It supports 5 to 24 VDC operation with ripple tolerance and includes an NPN output in Dark-ON/Light-ON selectable mode. With a durable PBT body, IP50 protection, and built-in protection circuitry, it withstands tough factory environments.
Due to its small footprint and robust sensing precision, the EE SX677 is widely used in applications such as printer mechanisms, robotic arms, packaging equipment, and position detection systems. When working in confined spaces or compact equipment layouts, many OEMs rely on the Omron EE-SX677 to maintain consistent detection, making it a reliable Omron R-Shaped Photo Micro Sensor.
