Omron EE-SX673P-WR 1M Photomicrosensor
Omron EE-SX673P-WR 1M is a grooved through-beam photomicrosensor built around a fixed 5 mm sensing slot and a 1 m pre-wired cable. Its infrared LED creates the optical path across the groove, while the PNP output provides the switching signal when a target passes through the sensing area. Light-ON and Dark-ON operation allows the output logic to be selected for the required control arrangement. The sensor operates from 5 to 24 VDC and has a stated current consumption of 30 mA. A switching frequency of at least 1 kHz supports responsive slot sensing in compact mechanisms. The EE-SX673P-WR 1M sits within the grooved photomicrosensor range from Omron industrial sensing.
| Brand | Omron |
| Product | Photomicro Sensors |
| Model Number | EE-SX673P-WR 1M |
Omron EE-SX673P-WR 1M Photomicrosensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensing Method | Through-beam |
| Shape | Grooved Type |
| Sensing Distance | 5mm |
| Power Supply Voltage | 5 to 24 VDC |
| Output Configuration | PNP |
| Connection Method | Pre-wired cable length 1m |
| Current Consumption | 30 mA |
| Light Source (Wavelength) | Infrared LED |
| Operation Mode | Light-ON/Dark-ON |
| Response Time | 1 kHz min |
| Degree Of Protection | IP50 |
| Material | Polybutylene terephthalate (PBT) |
| Material Lens | Polycarbonate (PC) |
| Weight | 16.8 g |
The Omron EE-SX673P-WR 1M Photomicrosensor uses a grooved through-beam arrangement with a fixed 5 mm sensing gap and a 1 m pre-wired cable. An infrared LED supplies the optical source across the groove, while the receiving side monitors the beam as an object moves through the opening. The sensor provides a PNP output and supports both Light-ON and Dark-ON operation, allowing its switching logic to be matched to the connected control circuit. Supply voltage is specified from 5 to 24 VDC, and current consumption is 30 mA. The supplied data also specifies a switching frequency of at least 1 kHz, supporting responsive operation where targets move through the slot repeatedly. The pre-wired cable provides direct electrical connection without requiring a connector at the sensor body.
The EE-SX673P-WR uses polybutylene terephthalate for the main housing together with polycarbonate material and has a stated weight of 16.8 g. The enclosure is rated IP50. Its grooved format keeps the transmitting and receiving sections aligned around the fixed 5 mm slot, making the sensing position physically defined by the sensor structure itself. The 1 m cable can be useful where wiring needs to extend from the mounting point before reaching a terminal or control interface. The supplied specifications identify the infrared LED, PNP configuration, selectable operating modes, and pre-wired connection without adding unsupported wavelength or response-time values. For a related PNP 5 mm slot model with a 1 m pre-wired cable and close-mounting format, see the Omron EE-SX674P-WR 1M.
