Omron EE-SX672R Photomicrosensor
Omron EE-SX672R is a T-shaped through-beam photomicrosensor designed around a fixed 5 mm sensing slot with the slot center positioned at 7 mm. Its integrated transmitting and receiving sections maintain a non-modulated optical path across the opening, allowing the PNP output state to change as a target moves through the slot. Dark-ON and Light-ON operation can be selected according to the required switching logic. The sensor operates from 5 to 24 VDC and consumes 12 mA with the L terminal open. Its output supports up to 50 mA load current, while a 4-pole connector provides removable electrical integration. A red indicator operates under the stated no-incident-light condition. The EE-SX672R supports the T-shaped PNP sensor range from Omron Slot Sensor Products.
| Brand | Omron |
| Product | Photomicro Sensors |
| Model Number | EE-SX672R |
Omron EE-SX672R Photomicrosensor – Technical Specifications
| Specification | Value |
|---|---|
| Type | T-shaped, slot center 7 mm |
| Sensing Method | Throughbeam with slot |
| Sensing Distance | 5 mm |
| Power Supply Voltage | 5 to 24 VDC |
| Control Output (Output Type) | PNP |
| Connection Method | Connector (4 poles) |
| Current Consumption | 12 mA (L terminal open) |
| Operation Mode | Dark-ON/Light-ON |
| Control Output (Residual Voltage) | at 50 mA load current: 1.3 V max. |
| Control Output (Load Current) | 50 mA max. |
| Indicator | No incident light (red) |
| Luminous Method | Non-modulated |
| Ambient Temperature (Operating) | -25 to 55 ℃ (with no freezing or condensation) |
| Ambient Temperature (Storage) | -30 to 80 ℃ (with no freezing or condensation) |
| Ambient Humidity (Operating) | 5 to 85 % (with no condensation) |
| Ambient Humidity (Storage) | 5 to 95 % (with no condensation) |
| Vibration Resistance | Destruction: 20 to 2000 Hz, peak acceleration 100 m/s2, 1.5-mm double amplitude 2 h each in X, Y, and Z directions (4 min periods) |
| Shock Resistance | Destruction: 500 m/s2 for 3 times each in X, Y, and Z directions |
| Degree Of Protection | IP50 |
| Material | Case: Polybutylene terephthalate (PBT) Emitter/Receiver Cover: Polycarbonate (PC) |
The Omron EE-SX672R Photomicrosensor uses a T-shaped through-beam arrangement across a fixed 5 mm sensing slot, with the slot center positioned at 7 mm. The internal sensing sections establish the optical path inside the sensor body, allowing components entering the opening to change the output state. It operates from 5 to 24 VDC and provides a PNP output with selectable Dark-ON or Light-ON switching. Current consumption is specified at 12 mA with the L terminal open, while maximum load current is 50 mA. Residual voltage is listed as 1.3 V max. with a 50 mA load. A 4-pole connector provides electrical connection, and the optical signal is non-modulated. The red indicator operates under the stated no-incident-light condition.
Featuring a PBT case with polycarbonate emitter and receiver covers, the EE-SX672R operates from -25°C to 55°C and can be stored from -30°C to 80°C without freezing or condensation. Its vibration specification covers 20 to 2,000 Hz with peak acceleration of 100 m/s² and 1.5 mm double amplitude during the stated test sequence. Shock resistance is specified at 500 m/s² three times along each X, Y, and Z direction, while the enclosure carries an IP50 rating. The PNP output, T-shaped profile, 7 mm slot center, and selectable switching logic define this model for compact slot sensing. For a related NPN model using the same T-shaped geometry, see the Omron EE-SX672A.
