Omron EE-SX671P-WR 1M Photomicrosensor
The Omron EE-SX671P-WR 1M Photomicrosensor offers L-shaped, Throughbeam with slot, 5 mm Sensing distance, PNP Output, Pre Wired, Cable Length 1M, Infrared LED, 5 to 24 VDC Power supply voltage, Dark-ON/ Light-ON (selectable) mode. Manufactured by Omron under the Omron Photoelectric Sensors category, this model belongs to the Omron EE Series.
| Brand | Omron |
| Product Type | Photomicro Sensor |
| Model Number | EE-SX671P-WR 1M |
Omron EE-SX671P-WR 1M Photomicrosensor β Technical Specifications
| Specification | Value |
|---|---|
| Appearance | L-shaped |
| Sensing Method | Throughbeam with slot |
| Sensing Distance | 5 mm |
| Light Source | Infrared LED |
| Power Supply Voltage | 5 to 24 VDC |
| Output configuration | PNP |
| Connection Method | Pre Wired, Cable Length 1M |
| Current Consumption | 12 mA max. |
| Operation Mode | Dark-ON/ Light-ON (selectable) |
| Indicators | Incident light |
| Ambient Illumination | 1,000 lx max. with fluorescent light on the surface of the receiver |
| Ambient Temperature Range | Operating: β25 to +55Β°C, Storage: β30 to +80Β°C (with no icing or condensation) |
| Ambient Humidity Range | Operating: 5% to 85%, Storage: 5% to 95% (with no icing or condensation) |
| Vibration Resistance | Destruction: 20 to 2,000 Hz (peak acceleration: 100 m/s2) 1.5-mm double amplitude for 2 h (4-min periods) each in X, Y, and Z directions |
| Shock Resistance | Destruction: 500 m/s2 for 3 times each in X, Y, and Z directions |
| Protection Circuits | Load short circuit protection |
| Degree of Protection | IEC60529 IP50 |
| Material | Polybutylene phthalate (PBT) |
Omron, a globally respected leader in industrial automation, offers advanced sensor technologies trusted for their durability and precision. Their photoelectric sensor range is engineered for fast, accurate detection even in harsh environments. The EE-SX series is widely used in packaging, labeling, printing, and assembly lines where space constraints and speed require compact, reliable sensing solutions.
The Omron EE-SX671P-WR 1M is an L-shaped throughbeam sensor designed with a fixed 5 mm slot width for precise detection of small objects passing through its sensing area. It uses a high-efficiency infrared LED operating at 940 nm and supports PNP output for easy PLC integration. The unit operates on 5 to 24 VDC and consumes just 12 mA, ensuring energy efficiency. Its dark-ON/light-ON selectable mode provides flexibility for a wide range of automation setups. The sensor is built with rugged PBT material and has an IP50 protection rating, suitable for environments with minimal dust exposure.
With fast response time and robust resistance to vibration and shock, the EE-SX671P-WR 1M excels in tight industrial spaces like label detection in bottling lines or part counting in precision equipment. Its compact body and pre-wired 1-meter cable ensure easy installation, while the incident light indicator allows quick visual status checks.
