| Shape | 48 × 48 mm |
| Power supply voltage | 100 to 240 VAC, 50/60 Hz |
| Operating voltage range/ Allowable voltage variable range | 85 to 110% of the power supply voltage |
| Power consumption | 4.9 VA max. at 100 to 240 VAC, and 2.8 VA max. at 24 VDC or 1.5 W max. at 24 VDC |
| Control method | ON/OFF control or 2-PID control (with auto-tuning) |
| Input Type/Temperature input | Thermocouple: K, J, T, E, L, U, N, R, S, B, C/W, or PL II
Platinum resistance thermometer: Pt100 or JPt100
Infrared temperature sensor (ES1B): 10 to 70°C, 60 to 120°C, 115 to 165°C, or 140 to 260°C |
| Control output 1 | Voltage output |
| Number of total auxiliary output | 2 point |
| Setting method | Digital setting using front panel keys |
| Indication method | 3,000 VAC, 50/60 Hz for 1 min between terminals of different charge |
| Insulation resistance | 10 to 55 Hz, 20 m/s2 for 2 hrs each in X, Y, and Z directions |
| Dielectric strength | 3,000 VAC, 50/60 Hz for 1 min between terminals of different charge |
| Vibration resistance | 10 to 55 Hz, 20 m/s2 for 2 hrs each in X, Y, and Z directions |
| Shock resistance | 300 m/s2, 3 times each in X, Y, and Z directions |
| Ambient temperature (Operating) | -10 to 55°C (with no condensation or icing) |
| Ambient temperature (Storage) | -25 to 65°C (with no condensation or icing) |
| Ambient humidity (Operating) | 25% to 85% |
| Degree of protection | Front panel: IP66, Rear case: IP20, Terminals: IP00 |
| Terminal type | Screw Terminals |
| Weight | Unit: Approx. 40 g |
