Omron E5CC-QX2ASM-003 Digital Temperature Controller
The Omron E5CC-QX2ASM-003 Temperature Controller is a compact and precise Digital Temperature Controller designed for stable, fast-response industrial temperature regulation. Its slim DIN 48 × 48 mm body supports a versatile 1 Point input compatible with multiple sensor types for accurate measurement and control.. Operating on 100 to 240 VAC (50/60 Hz) with an allowable range of 85 to 110% of the power supply voltage, it provides ON/OFF control or 2-PID control (with auto-tuning) for highly stable temperature management. The controller includes a Voltage output (for driving SSR), Digital setting using front panel keys, and 11-segment digital display for clear monitoring. Built with a case and Screw terminal block wiring, it ensures easy integration into control panels. Manufactured by Omron, part of the Omron Temperature Controller ecosystem within the Omron E5CC Series.
Omron E5CC-QX2ASM-003 Temperature Controller - Technical Specifications
Specification
Value
Shape
DIN 48 × 48 mm
Power supply voltage
100 to 240 VAC (50/60 Hz)
Operating voltage range/ Allowable voltage variable range
85 to 110% of the power supply voltage
Power consumption
6.5 VA max. (at 100 to 240 VAC)
Control method
ON/OFF control or 2-PID control (with auto-tuning)
Number of input points
1 Point
Input Type/Temperature input
Thermocouple: K, J, T, E, L, U, N, R, S, B, C/W, PLII
Platinum resistance thermometer: Pt100, JPt100
Infrared Thermosensor: 10 to 70 ℃, 60 to 120 ℃, 115 to 165 ℃, 140 to 260 ℃
Control output 1
Voltage output (for driving SSR)
Control output 2
None
Setting method
Digital setting using front panel keys
Indication method
11-segment digital display and individual indicators
Character height: PV: 15.2 mm, SV: 7.1 mm
Insulation resistance
20 MΩ min. (at 500 VDC)
Dielectric strength
3,000 VAC, 50/60 Hz for 1 min between terminals of different charge
Vibration resistance
Malfunction 10 to 55 Hz, 20 m/s2 for 10 min each in X, Y, and Z directions
Resistance 10 to 55 Hz, 20 m/s2 for 2 hrs each in X, Y, and Z directions
Shock resistance
Malfunction 100 m/s2, 3 times each in X, Y, and Z directions
Resistance 300 m/s2, 3 times each in X, Y, and Z directions
Ambient temperature (Operating)
-10 to 55°C (with no condensation or icing)
Ambient temperature (Storage)
-25 to 65°C (with no condensation or icing)
Ambient humidity (Operating)
25 to 85 %
Degree of protection
Front panel: IP66, Rear case: IP20, Terminals: IP00
Terminal type
Screw terminal block
Weight
Approx. 120 g, Mounting Adapter: Approx. 10 g
The Omron E5CC-QX2ASM-003 is frequently assessed alongside other units in the Digital Temperature Controllers group because they share comparable sensor inputs, panel depth behaviour, and loop-control characteristics. Engineers often evaluate Omron E5CC-QQ3DSM-000 (DIN48 x 48, ON/OFF or 2-PID control, 24 VAC (50/60 Hz); 24 VDC, Voltage output (for driving SSR), 11-segment digital display), Omron E5CC-CQ3ASM-002 (DIN48 x 48, ON/OFF or 2-PID control, 100 to 240 VAC (50/60 Hz), Linear current output, 11-segment digital display), and Omron E5CC-RX2ASM-005 (DIN48 x 48, ON/OFF or 2-PID control, 100 to 240 VAC (50/60 Hz), Relay output, 11-segment digital display) when selecting a controller that fits panel wiring, SSR/relay load stages, and enclosure thermal limits. Reviewing shape, control method, supply voltage class, output structure, and indication style builds a clearer link between field sensors, heater.
