Omron E3Z-LS86-UL Photoelectric Sensor
The Omron E3Z-LS86-UL Photoelectric Sensor offers Distance-settable, 40 min. to 200 min. Incident threshold (FGS setting)
Sensing distance, PNP Output, M8 (4-pin) Connector, Red LED (670 nm), 12 to 24 VDC, Class 2, Light-ON/Dark-ON selectable mode. Manufactured by Omron under the Omron Photoelectric Sensors category, this model belongs to the Omron E3Z Series.
| Brand | Omron |
| Product Type | Photoelectric Sensor |
| Model Number | E3Z-LS86-UL |
Omron E3Z-LS86-UL Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing Method | Distance-settable |
| Sensing Distance | 40 min. to 200 min. Incident threshold (FGS setting) |
| Light Source | Red LED (670 nm) |
| Power Supply Voltage | 12 to 24 VDC, Class 2 |
| Output configuration | PNP |
| Connection Method | M8 (4-pin) Connector |
| Current Consumption | 30 mA max. |
| Control Output | Load power supply voltage: 26.4 VDC max., Load current: 100 mA max. (residual voltage 1 V max.), Open collector output (NPN or PNP depending on model) |
| Operation Mode | Light-ON/Dark-ON selectable |
| Response Time | Operate or reset: 1 ms max. |
| Sensitivity Adjustment | 5-turn endless adjuster |
| Indicators | Operation indicator (orange), Stability indicator (green) |
| Ambient Illumination | Incandescent lamp: 3,000 lx max.; Sunlight: 10,000 lx max. |
| Ambient Temperature Range | Operating: β25 to 55Β°C, Storage: β40 to 70Β°C (with no icing or condensation) |
| Ambient Humidity Range | Operating: 35% to 85%, Storage: 35% to 95% (with no condensation) |
| Insulation Resistance | 20 MΞ© min. at 500 VDC |
| Dielectric Strength | 1,000 VAC at 50/60 Hz for 1 minute |
| Vibration Resistance | Destruction: 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions |
| Shock Resistance | Destruction: 500 m/s2 for 3 times each in X, Y, and Z directions |
| Protection Circuits | Reversed power supply polarity protection, Output short-circuit protection, Mutual interference prevention |
| Degree of Protection | IP67 (IEC 60529) |
| Weight | Approx. 20 g |
The Omron E3Z-LS86-UL is a compact, high-performance photoelectric sensor featuring a distance-settable design for flexible object detection. With a visible red LED light source (670 nm), this sensor ensures accurate alignment and detection. It supports a minimum incident threshold of 40 mm and a maximum of 200 mm, making it suitable for applications involving variable object positions or backgrounds.
Operating on a 12 to 24 VDC power supply (), the E3Z-LS86-UL offers a PNP open collector output and supports a load current up to 100 mA. The connection is handled via a 4-pin M8 connector, simplifying installation and maintenance in modular industrial setups. Its maximum current consumption is 30 mA, and it features reverse polarity and output short-circuit protection for safe integration into control systems.
The sensor supports both Light-ON and Dark-ON selectable modes, with a quick 1 ms max. response time suitable for fast-moving production lines. Fine-tuning is made easy with a 5-turn endless adjuster, allowing for precise control over sensitivity depending on target reflectivity and distance. The E3Z-LS86-UL includes two LED indicators: an orange operation light and a green stability indicator, giving real-time status feedback to technicians during setup or runtime.
Designed for durability, the sensor operates within β25Β°C to 55Β°C and tolerates storage down to β40Β°C. It also withstands ambient illumination up to 10,000 lx sunlight and 3,000 lx from incandescent lamps. With strong resistance to vibration (10 to 55 Hz, 1.5 mm double amplitude) and shock (500 m/sΒ²), the Omron E3Z-LS86-UL is ideal for tough industrial conditions.
It meets IP67 protection standards (IEC 60529) and includes built-in mutual interference prevention for reliable multi-sensor operation. The E3Z-LS86-UL is commonly used in packaging lines, component detection, and position confirmation where compact, adjustable, and durable sensing is required.
