Omron E3Z-G61-M3J 0.3M Photoelectric Sensor
The Omron E3Z-G61-M3J 0.3M Photoelectric Sensor offers Through-beam, Grooved Type, 25 mm Sensing distance, NPN Output, Pre-wired Connector M8, Infrared LED (940 nm), 12 to 24 VDC Power supply voltage, Light-ON/Dark-ON mode. Manufactured by Omron under the Omron Photoelectric Sensors category, this model belongs to the Omron E3Z Series.
| Brand | Omron |
| Product Type | Photoelectric Sensor |
| Model Number | E3Z-G61-M3J 0.3M |
Omron E3Z-G61-M3J 0.3M Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Appearance | Grooved Type |
| Sensing Method | Through-beam |
| Sensing Distance | 25 mm |
| Light Source | Infrared LED (940 nm) |
| Power Supply Voltage | 12 to 24 VDC |
| Output configuration | NPN |
| Connection Method | Pre-wired Connector M8 |
| Current Consumption | 25 mA max. |
| Operation Mode | Light-ON/Dark-ON |
| Response Time | Operate or reset: 1 ms max. |
| Sensitivity Adjustment | One-turn adjuster |
| Ambient Illumination | Incandescent lamp: 3,000 lx max. Sunlight: 10,000 lx max |
| Ambient Temperature Range | Operating: β25 to 55Β°C, Some connector models: β40Β°C to 55Β°C * (with no icing or condensation) Storage: β40 to 70Β°C (with no icing or condensation) |
| Ambient Humidity Range | Operating: 35% to 85%, Storage: 35% to 95% (with no condensation) |
| Insulation Resistance | 20 MΞ© min. at 500 VDC |
| Dielectric Strength | 1,000 VAC, 50/60 Hz for 1 min |
| Vibration Resistance | Destruction: 10 to 55 Hz, 1.5 mm double amplitude for 2 hours each in X, Y, and Z directions |
| Shock Resistance | Destruction: 500 m/s2 3 times each in X, Y, and Z directions |
| Protection Circuits | Reversed power supply polarity protection, Output short-circuit protection, and Mutual interference prevention |
| Degree of Protection | IP64 (IEC 60529) |
| Material | ABS (Acrylonitril Butadiene Styrene) |
| Weight | Approx. 30 g |
Omron has built a legacy of innovation and precision in factory automation, with sensors that combine rugged design and reliable performance. The Omron E3Z-G61-M3J 0.3M reflects this standard, offering a slim, grooved build with accurate detection capabilities in limited-space environments. Designed with durability and ease of integration in mind, the E3Z G61 M3J 0.3M stands out as a dependable Omron Compact Photoelectric Sensor for modern industrial machines.
The Omron E3Z-G61-M3J 0.3M features a through-beam sensing method using a 940 nm Infrared LED and operates on 12 to 24 VDC . It delivers fast 1 ms response time, includes NPN output configuration, and has a pre-wired M8 connector for easy integration. Built with ABS material, this unit weighs only 30 g and carries an IP64 rating, making it suitable for dusty environments.
With a sensing gap of 25 mm and a one-turn sensitivity adjuster, the E3Z G61 M3J 0.3M is ideal for detecting the presence of thin parts on conveyors, small object positioning in assembly lines, and integration in robotic grippers. Compact yet powerful, the Omron E3Z-G61-M3J 0.3M enhances accuracy and reliability in industrial systems, making it a preferred Omron Compact Photoelectric Sensor for space-critical applications.
